86
AVR-3310CI/AVR-3310/AVR990/AVC-3310
18
P82/INT0 SUB BDOWN I -
E
↓
&L
Eu Z - - Z Power down detect (Power down: L)
19
P81 IP RST O C - - - Z O/H O/H Z IP CONV(ABT2010) reset
20
P80/(RXD5) VZ2INH O C - - - Z O/L O/L Z Video input switching(Z2 INPUT INH selection)
21
P77/(CLK5) /TDO I - - - - Z O/L O/L Z /PLDrewrite control (JTAG)
22
P76/(TXD5) A PLD CS /TMS/
"D/M"
O C - - Eu Z O/L - O/L A PLD control pin /PLD rewrite (JTAG)/DENON
WRITER/For MITSUBISHI rewrite distinction (DW="L")
23
P75 A PLD DATA/TDI O C - - - Z O/L O/L Z A PLD control pin /PLDrewrite control (JTAG)
24
P74 A PLD CLK/
MTCK
O C - - - Z O/L O/L Z A PLD control pin /PLDrewrite control (JTAG)
25
P73/CTS2 ANALOG VIDEO
POWER
O C - - - Z O/L O/L Z VIDEO power ON/OFF control (H: ON)
26
P72/CLK2 DIGITAL POWER O C - - Ed Z Z - Z DIGITAL power ON/OFF control (H: ON)
27
P71/RXD2/
SCLMM
HSCL(400k) I/O N - - Eu Z O/L O/L O/L VIDEO I2C- IP CONV(ABT2010)/
HDMI_RECEIVER(ADV7840)/HDMI TRANSMITTER1
(ADV7510)
28
P70/TXD2/
SDAMM
HSDA(400k) I/O N - - Eu Z O/L O/L O/L VIDEO I2C- IP CONV(ABT2010)/
HDMI_RECEIVER(ADV7840)/HDMI TRANSMITTER1
(ADV7510)
29
P67/TXD1 TXD O C - - Eu Z - - Z Data transfer output to outside
30
P66/RXD1 RXD I - Lv - Eu Z - - Z Data receive input from outside
31
P65/CLK1 FGAIN O C - - Ed Z - O/L Z FGAIN control pin
32
P64/CTS1 CFSEL0 I - Lv - - Z - - Z COMPONENT HD OUT Filter switching
33
P63/TXD0 SOMI O C - - - Z - - Z
MAIN-SUB
μ
com comm. control pin
34
P62/RXD0 SIMO I - - - Ed Z - - Z
MAIN-SUB
μ
com comm. control pin
35
P61/CLK0 CLK SIMO I - - - Ed Z - - Z
MAIN-SUB
μ
com comm. control pin
36
P60/CTS0 REQ SOMI O C - - Ed Z - - Z
MAIN-SUB
μ
com comm. control pin
37
P57 1TMDS SW RST O C - - - Z O/H - Z HDMI SWITCHER ADV3002 Reset pin
38
P56 HPD2 O C - - - Z O/L - Z HD DET control pin
39
P55/EPM ADC RST/EPM O C - - Ed Z - - Z AD(PCM1804) control pin /Rewrite boot start : L input
set
40
P54 CEC_OUT O C - - - Z O/L - Z CEC-D signal output pin
41
P53 MONI DIS O C - - Z O/L O/L Z COMPONENT MONITOR OUT output control pin
42
P52 DVR INH O C - - - Z O/L O/L Z DVR OUT output INH control(L:MUTE)
43
P51 VCR INH O C - - - Z O/L O/L Z VCR OUT output INH control(L:MUTE)
44
P50/CE /CE O - - - Eu Z O/L - Z pin/ rewrite boot program start : H input set
45
P47/(TXD7)/
SDA7
VSDA I/O C - - Eu Z O/L - O/L ENCODER ADV7340 I2C/COMPONENT SELECT
IC(NJW1321FP1)
46
P46/(RXD7)/
SCL7
VSCL I/O C - - Eu Z O/L - O/L ENCODER ADV7340 I2C/COMPONENT SELECT
IC(NJW1321FP1)
47
P45/(CLK7) HPD1 O C - - Ed Z O/L - Z HD DET control pin
48
P44 Z2 MONIA O C - - Ed Z O/L O/L Z ZONE2 MONITOR OUT select
49
P43 HDMI A.SEL O C - - Ed Z O/L O/L Z HDMI AUDIO control (H: FDSP route, L: FHDMI Rx Å®
Tx through)
50
P42 Z2SSIG.DET I - Lv - Ed Z I I Z ZONE2 S signal detect input (Connected: H)
51
P41 CEC PWR O C - - Ed Z O/L O/H Z H:CEC STANDBY Power ON
52
P40 Z1 SMONIA O C - - Z O/L O/L Z Z1 S MONITOR select
53
P37 HDMIR_RST O C - - Eu Z O/H - Z HDMI RECEIVER(ADV7840) reset
54
P36 1TX RST O C - - Eu Z O/H - Z HDMI TRANSMITTER1 (ADV7510) reset
55
P35 Z1 SMONIB O C - - Ed Z O/L O/L Z Z1 SMONITOR select
56
P34 Z1 SSIGDET I - - - Eu Z - - Z S signal detect input (Connected: H)
57
P33 VZ1INH O C - - Ed Z O/L - Z Video input switching(Z1 INPUT INH select)
58
P32 DAC MDI O C - - - Z O/L O/L Z DAC control pin (AK4358)
59
P31 DAC MC O C - - - Z O/L O/L Z DAC control pin (AK4358)
60
VCC VCC - - - - - - - - - +3.3V
61
P30 DAC MS O C - - - Z O/L O/L Z DAC control pin (AK4358)
62
VSS VSS - - - - - - - - - GND
63
P27 DAC RST O C - - - Z O/H O/L Z DAC control pin (AK4358)
64
P26 DIG VIDEO
POWER
OC - - - Z O/L
MODE1=O/H
MODE2=O/L
Z
DIGITAL VIDEO power control pin
65
P25/INT7 OSD CPU
BUSYSI
I - Lv - - Z - - Z OSD CPU control pin
66
P24/INT6 1TX INT I - Lv - . Z - - Z HDMI OUT1 signal detect input (HDMI TRANS1
ADV7510)
67
P23 NC O C - - - Z O/L O/L Z NC
68
P22 VEXP STB O C - - - Z O/L O/L Z VIDEO expander control pin output(BU4094BCFV)
69
P21 VEXP OE O C - - Ed Z O/L O/L Z VIDEO expander control pin output(BU4094BCFV)
70
P20 VEXP CLK O C - - - Z O/L O/L Z VIDEO expander control CLK output(BU4094BCFV)
71
P17/INT5 ADVINT1 I -
E
↓
&L
- - Z - - Z HDMI RECEIVER(ADV7840)INT1 output
72
P16/INT4 ADVINT2 I -
E
↓
&L
- - Z - - Z HDMI RECEIVER(ADV7840)INT2 output
Pin Pin Name Symbol I/O Type Det
Op
(Int.)
Pu/Pd
(Ext.)
Res
PURE D
CEC STBY
P.OFF
Function
