AVR-3310CI/AVR-3310/AVR990/AVC-3310
73
P15/INT3 ADVINT3 I -
E
↓
&L
- - Z - - Z HDMI RECEIVER(ADV7840)INT3 output
74
P14 Z2 MONIB O C - - Eu Z O/L O/L Z ZONE2 MONITOR OUT select
75
P13/TXD6 DSP MOSI O C - - Eu Z O/L O/L Z DSP control pin (ADSP-21367-333)
76
P12/RXD6 DSP MISO I - - - Eu Z - - Z DSP control pin (ADSP-21367-333)
77
P11/CLK6 DSPICLK O C - - Eu Z O/L O/L Z DSP control pin (ADSP-21367-333)
78
P10 Z1VSIG.DET I - Lv - Eu Z - - Z VIDEO IN signal detect input (Detected : H)
79
P07 PLD WRITE O C - - - Z O/L O/L Z PLD JTAGLINE ON/OFF control
80
P06 VPLD CE O C - - Ed Z O/L
MODE1=O/H
MODE2=O/L
Z
VIDEO PLD control pin
81
P05 HPD3 O C - - - Z O/L - Z HD DET control pin
82
P04 HPD4 O C - - - Z O/L - Z HD DET control pin
83
P03 HPD5 O C - - - Z O/L - Z HD DET control pin
84
P02 DIR RST3 I - Lv - Z - - Z DIR control pin (LC89058W-VF4A)
85
P01 DIR RST2 O C - - Z O/L O/L O/L DIR control pin (LC89058W-VF4A)
86
P00 DIR RST1 O C - - - Z O/L O/L O/L DIR control pin (LC89058W-VF4A)
87
P107/(AN7) DSP RST O C - - - Z O/L O/L Z DSP2(ADSP-21367-333) reset output pin(Reset:L)
88
P106/(AN6) O C - - - Z O/L O/L Z
89
P105/(AN5) DSP ROMRST O C - - Ed Z O/L O/L Z DSP memory reset(reset: L)
90
P104/(AN4) COMPS DET I - Lv - Eu Z - - Z COMPONENT IN signal detect input
91
P103/(AN3) DSP FLAG0 I - Lv - Ed Z - - Z DSP control pin (ADSP-21367-333)
92
P102/(AN2) DSPICS O C - Eu Z O/L O/L Z DSP control pin (ADSP-21367-333)
93
P101/(AN1) O C - Eu Z O/L O/L Z
94
AVSS AVSS - - - - - - - - - AD GND
95
P100/(AN0) VPLD CLK O C - - - Z O/L O/L Z VIDEO PLD control pin
96
VREF VREF - - - - - - - - - AD ref. +3.3V
97
AVCC AVCC - - - - - - - - - AD +3.3V
98
P97/(SIN4) O C - - - Z O/L - Z
99
P96/(SOUT4) OSD CPU
BUSYSO
O C - - - Z O/L O/L Z OSD CPU control pin
100
P95/(CLK4) VEXP DIN O C - - - Z O/L O/L Z VIDEO expander control DATA output(BU4094BCFV)
