L
R
++
OUTPUT
INPUT
AUX OUT
(
L
) (
R
)
13
Connecting the video component equipped with V. AUX jacks
To connect the video signal, connect using a 75 Ω/ohms video signal cable cord.
R VIDEO OUT S-VIDEO OUTOPTICALL
R VIDEO OUTL
OUTPUT
OUTPUT
LINE OUT
DIGITAL OUT
VIDEO OUT
S-VIDEO OUT
VIDEO OUT
LINE OUT
S-VIDEO OUT
S-VIDEO OUT
L
R
L
R
L
R
Connecting a Video game component
• Connect the Video game component’s output jacks
to this unit’s V. AUX INPUT jacks.
Video game
Video camera
Connecting a video camera component
• Connect the video camera component’s output
jacks to this unit’s V. AUX INPUT jacks.
[3] ZONE2/ZONE3 SPEAKER OUT and PREOUT CONNECTIONS
• If another power amplifier or pre-main (integrated) amplifier is connected, the ZONE2/ZONE3 output terminals can be used to play a different
program source in ZONE2/ZONE3 the same time.
• ZONE2/ZONE3 SPEAKER OUT can be used when “ZONE2/ZONE3” is selected at System Setup Menu “Power Amp Assign”. In this case ,
Surround Back Speaker OUT cannot be used for MAIN ZONE. (See page 45)
ZONE2/ZONE3
RC-616
INFRARED
RETRANSMITTER
RC-617
INFRARED SENSOR
Extension jacks for future use.
SURROUND BACK/ZONE2/ZONE3 SPEAKER SYSTEMS
NOTE:
• The settings must
be changed to use
this speaker for
ZONE2/ZONE3.
(See page 45.)
Power amplifier
To Next Page
