Denon AVR-3805 User Manual

51
Operating DENON audio components
1
Use the mode selector buttons to select the component you
want to operate.
The function switches as shown below each time one of
the mode buttons is pressed.
AMP/TUNER : AMP, TUNER
ZONE2/ZONE3 : ZONE2, ZONE3
TAPE/MD : TAPE, MD
CD/CDR : CD, CDR
TV/DBS/CABLE : TV, DBS, CABLE
VCR1/VCR2 : VCR1,VCR2
VDP : VDP
DVD/DVDR : DVD,DVDR
Example: Select“AMP”mode. Select“TUNER”mode.
2
Operate the audio component.
• For details, refer to the component’s operating instructions.
It may not be possible to operate some models.
1. CD player (CD) system buttons
6, 7 : Manual search
(forward and reverse)
2 : Stop
1 :Play
8, 9 : Auto search
(to beginning of track)
3 : Pause
DISC SKIP + : (for CD changers only)
0~9, +10 : 10 Key
1
3
3
[SOURCE MENU]
• Operate the source.
[SURROUND MENU]
• Operate the surround mode.
[10KEY / SYSTEM CALL MENU]
• Operate the 10KEY or SYSTEM CALL mode.

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
