SURROUND
Before playing with the surround function
• Before playing with the surround function, be sure to use the test tones to adjust the playback level from the different speakers. This adjustment
can be performed with the system setup (see page 34~35) or from the remote control unit, as described below.
• Adjusting with the remote control unit using the test tones is only possible in the “Auto” mode and only effective in the STANDARD
(DOLBY/DTS SURROUND) modes. The adjusted levels for the different modes are automatically stored in the memory.
1
Press the TEST TONE button.
2
Test tones are output from the
different speakers. Use the channel
volume adjust buttons to adjust so
that the volume of the test tones is
the same for all the speakers.
• After adjusting using the test tones, adjust the channel levels either according to the playback sources or to suit your tastes, as described below.
3
After completing the adjustment,
press the TEST TONE button again.
1
Select the speaker level you want to
adjust.
(Remote control unit)
2
Adjust the level of the selected
speaker.
The channel switches as shown below each time the button
is pressed.
When the surround back speaker setting is set to “1spkr” for
“Speaker Configuration”, this is set to “SB”.
(Remote control unit)
(Remote control unit)
(Remote control unit)
FL C FR SR SBR SBL
SLSW
FADER
NOTES:
• The adjustment range for the different channels is +12 dB to
–12 dB.
• The sound from the subwoofer can be cut by lowering the SW
(subwoofer) setting one step from –12 dB (setting it to “OFF”).
(Remote control unit)
