73
Fader function
• This function makes it possible to lower the volume of the front channels (FL, C and FR) or the rear channels (SL, SR, SBL and SBR) together.
Use it for example to adjust the balance of the sound from each position when multi-channel music sources are played.
1
Select “FADER”.
2
Press the 0 button to reduce the volume of the front
channels, the 1 button to reduce the volume of the rear
channels.
The channel switches in the order shown below each time
this button is pressed.
The fader function does not affect the SW channel.
The channel whose channel level is adjusted lowest can be faded
to –12 dB using the fader function.
If the channel levels are adjusted separately after adjusting the
fader, the fader adjustment values are cleared, so adjust the fader
again.
Dolby Pro Logic
II
x (Pro Logic
II
) mode
1
Select the Dolby Pro Logic IIx mode.
2
Play a program source with the mark.
• For operating instructions, refer to the manuals of the
respective components.
This is only displayed when setting the fader control.
(Main unit)(Remote control unit)
FL C FR SR SBR SBL
SLSW
FADER
(Remote control unit)
(Remote control unit)
The Dolby Surround Pro
Logic II Cinema, Music or
Game mode can be
chosen directly by
pressing the CINEMA,
MUSIC or GAME button
on the remote control unit
during playback in the
Dolby Pro Logic IIx mode.
CH SEL
ENTER
(Main unit)
(Main unit)
To play in the PL IIx mode, set “Sp.Back” at the Speaker Configuration setting to “1Spkr” or “2Spkr”.
To play in the PL IIx mode, set “Surround Back” at the Power Amp Assign setting.
(Remote control unit)
