21
3
Digital In
Assignment
This assigns the digital input jacks for the different input
sources.
Input
source
Digital
Inputs
CD DVD VDP
TV
DBS V. AUX VCR-1 VCR-2
COAX1 COAX2 OPT1 OFF OPT2 OPT5 OPT3 OFF
1
CDR/TAPE
OPT4
Auto Surround
Mode
Set the Auto surround mode function.
Auto Surround Mode = ON
1
Audio Delay
Set the audio delay to delay time the sound and synchronize it with
the picture.
0 ms
3.Input Setup
2
Ext. In
Subwoofer
Level
Set the Ext. In Subwoofer terminal playback level. Subwoofer = +15 dB
This assigns the color difference (component) video input jacks for
the different input sources.
Video Input
Mode
Set the input signal to be output from the monitor output terminal.
Component
In Assign
3
4
DVD VDP TV
DBS
VCR-1 VCR-2 V. AUX —
VIDEO1 NONE VIDEO2 VIDEO3 NONE NONE NONE —
—
—
AUTO
4.Advanced Playback
Input Setup Default settings
Advanced Playback Default settings
2
Dolby Digital
Setup
Turn the audio compression on or off when down-mixing Dolby
Digital signals.
OFF
Set this to switch the surround back channel’s power amplifier for
use for zone2 or zone3.
Surround Back
Power AMP
Assignment
1
6
5
Muting Level
This sets the amount of attenuation at audio output muting. ---dB(minimum)
5.Option Setup
Option Setup Default settings
2
Zone2 vol.
Level
This sets the output level the zone2 output jacks.
This menu is not displayed, when “ZONE2” is selected at Option
Setup “Power Amp Assign”.
Variable
On Screen
Display
This sets whether or not to display the on-screen display that
appears on the monitor screen when the controls on the remote
control unit or main unit are operated.
A setting to prevent flickering.
On Screen Display = ON / Mode 1
5
Auto Tuner
Presets
FM stations are received automatically and stored in the memory.
A1 ~ A8
B1 ~B8
C1 ~C8
D1 ~D8
E1 ~E8
87.5/89.1/98.1/107.9/90.1/90.1/90.1/90.1 MHz
520/600/1000/1400/1500/1710 kHz/90.1/90.1 MHz
90.1 MHz
90.1 MHz
90.1 MHz
F1 ~F8 90.1 MHz
G1 ~G8 90.1 MHz
4
7
Setup Lock
Set whether or not to lock the system setup settings so that they
cannot be changed.
Setup Lock = OFF
Trigger Out1
Setup
Set the Trigger Out1 output for the each input sources.
PHONO CD TUNER
CDR/TAPE
DVD VDP TV VCR-1
OFF OFF OFF OFF ON ON ON ON
3
VCR-2
ON
DBS
ON
V. AUX
ON
Trigger Out2
Setup
Set the Trigger Out2 output for the each input sources.
PHONO CD TUNER
CDR/TAPE
DVD VDP TV VCR-1
ON ON ON ON ON ON ON ON
VCR-2
ON
DBS
ON
V. AUX
ON
ZONE=MAIN
ZONE=2
NOTES:
• The on-screen display signals are output with priority to the S-VIDEO MONITOR OUT jack during playback of a video component. For example, if the TV monitor
is connected to both the AVR-3805’s S-Video and video monitor output jacks and signals are input to the AVR-3805 from a video source (VDP, etc.) connected to
both the S-Video and video input jacks, the on-screen display signals are output with priority to the S-Video monitor output. If you wish to output the signals to
the video monitor output jack, do not connect a cord to the S-VIDEO MONITOR OUT jack. (For details, see page 49.)
• The AVR-3805’s on-screen display function is designed for use with high resolution monitor TVs, so it may be difficult to read small characters on TVs with small
screens or low resolutions.
• The setup menu is not displayed when headphone are being used.
