77
4
Display the
surround parameter
menu.
(Main unit)(Remote control unit)
5
Select the various parameters.
CH SEL
ENTER
6
CH SEL
ENTER
(Main unit)(Remote control unit)
CH SEL
ENTER
CH SEL
ENTER
(Main unit)(Remote control unit)
Adjust the parameter settings.
NOTE:
When Default is selected and the 0 cursor button is pressed, CINEMA EQ. and D.COMP. are automatically turned off, LFE is reset,
and the tone is set to the default value.
NOTE: The display on the screen differs depending on
whether you are performing the operation from
the main unit or the remote control unit.
2 Dialogue Normalization
The dialogue normalization function is activated automatically when playing Dolby Digital program sources.
Dialogue normalization is a basic function of Dolby Digital which automatically normalizes the dialog level (standard level) of the signals which are
recorded at different levels for different program sources, such as DVD, DTV and other future formats that will use Dolby Digital.
These contents can be verified with the STATUS and ON SCREEN button.
The number indicates the normalization level when the currently playing program is normalized to the
standard level.
Display
Checking the input signal
The input signal can be checked by pressing the remote control units ON
SCREEN button. (See page 41.)
SIGNAL: Displays the type of signal (DTS, DOLBY DIGITAL, PCM, etc.).
fs: Displays the input signals sampling frequency.
FORMAT: Displays the input signals number of channels.
Number of front channels/Number of surround channels/LFE on/off
SURROUND is displayed for 2-channel signal sources recorded in Dolby Surround.
OFFSET: Displays the dialog normalization offset value.
FLAG: Displays the special identification signal recorded in the input signal. (See page 51.)
MATRIX is displayed when matrix processing is conducted on the surround back
channel, DISCRETE is displayed when discrete processing is conducted.
Not displayed when no identification signal is recorded.
In addition, screen information is displayed in the following order when the ON SCREEN button is
pressed repeatedly:
OSD-1 Input signal
OSD-2 Input/output
OSD-3 Auto surround mode
OSD-3 ~ 9 Tuner preset stations
NOTE:
OSD-3: This is displayed when the auto surround mode is set to ON and the input mode is set to Auto.
It is not displayed when the input mode is set to Analog or EXT. IN.
(Remote control unit)
Offset -4dB
Dial.Norm
