Denon AVR-391 Service Manual

102
HDM P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC11 943236010380S IC ADV7622BSTZ CVIADV7622BSTZ *
IC15 943239010400S REGULATOR IC NJM2845DL133 CVINJM2845DL133
IC16 nsp IC EX3AV CVIEX3AV
Q101 00D2690184907 CHIP TR KRA102S HVTKRA102S
Q102 90M-BA001620R CHIP TR KRC103S CVTKRC103S
Q103 00D2690184907 CHIP TR KRA102S HVTKRA102S
Q104 90M-BA001620R CHIP TR KRC103S CVTKRC103S
Q105 00D2690184907 CHIP TR KRA102S HVTKRA102S
Q106 90M-BA001620R CHIP TR KRC103S CVTKRC103S
Q107 00D2690184907 CHIP TR KRA102S HVTKRA102S
Q108 90M-BA001620R CHIP TR KRC103S CVTKRC103S
RESISTORS GROUP
RN11,12 nsp RESNETWORK CHIP (33ohm 1/16W) CRJ064IJ330T
CAPACITORS GROUP
C101-129 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C130 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C131 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C132 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C133 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C134 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C135 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C136 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C138 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C139 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C140 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C141 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C144 nsp CHIP CAP 0.1UF 50V CCUS1H104KC
C145,146 nsp CHIP CAP 47PF 50V CCUS1H470JA
C147 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C148 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C149 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C150 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C161 nsp CHIP CAP 1UF 10V CCUS1A105KC
C162 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C163 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C164 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C165 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C166 nsp CHIP CAP 0.22UF 16V CCUS1C224KC
C167 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C171 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C172 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C173 nsp CHIP CAP 22UF 6.3V CCUP0J226KC
C174 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C175 nsp CHIP CAP 0.1UF 16V CCUI1C104KC
C176 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
d

Denon AVR-391 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Dolby Formats	Dolby Digital, Dolby Pro Logic II
Audio Return Channel	Yes
Component Video Inputs	2
Digital Optical Inputs	1
Digital Coaxial Inputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Power Output	75 Watts per channel
DTS Formats	DTS
Tuner Frequency Range	FM: 87.5 - 108 MHz
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Dimensions	434 x 151 x 319 mm
Weight	8.5 kg
