Denon AVR-391 Service Manual

63
PARTS LIST OF EXPLODED VIEW
zParts for which "nsp" is indicated on this table cannot be supplied.
z
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
zPart indicated with the mark " ★ " is not illustrated in the exploded view.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
1311E2 : Europe model 1311E1C : China model
391E3 : U.S.A. & Canada model 391E3B : Brazil model s 391EA : Australia model
BK : Black model SP : Premium Silver model
Ref.No. Part No. Part Name Remarks Q'ty New
C10' nsp FRONT P.W.B. UNIT ASS'Y COP12291U *
C10 nsp FRONT UNIT
C1 - AUX UNIT
C2 - PHONE UNIT
C3 - VOLUME UNIT
C9 - POWER UNIT
C8 - HEADPHONE UNIT
C13 - REGULATOT UNIT
C5' nsp MAIN P.W.B. UNIT ASS'Y 1311E2 COP12292E *
C5' nsp MAIN P.W.B. UNIT ASS'Y 1311E1C COP12292C *
C5' nsp MAIN P.W.B. UNIT ASS'Y 391E3,391E3B COP12292L *
C5' nsp MAIN P.W.B. UNIT ASS'Y 391EA COP12292N *
C5 - MAIN UNIT
C11 - WIRE SUPPORT UNIT
C6 nsp INPUT P.W.B. UNIT ASS'Y 1311E2 COP12293E *
C6 nsp INPUT P.W.B. UNIT ASS'Y 1311E1C COP12293C *
C6 nsp INPUT P.W.B. UNIT ASS'Y 391E3,391E3B COP12293L *
C6 nsp INPUT P.W.B. UNIT ASS'Y 391EA COP12293N *
C7 943189009470D HDMI P.W.B. UNIT ASS'Y COP12294U *
P1 943412009840D VOLUME KNOB BK CBN1A249 1 *
P1 943412009850D VOLUME KNOB SP CBN1A249C73 1 *
P2 963419010060D RCA COVER BK CGR1A510ZB28 1
P2 963419011380D RCA COVER SP CGR1A510YG45 1
P3 943402009680D FRONT PANEL 1311BKE2 CGW1A500B28Z 1 *
P3 943402009690D FRONT PANEL 1311SPE2,1311SPE1C CGW1A500RGG45Z 1 *
P3 943402009670D FRONT PANEL 391BKE3,391BKE3B,391BKEA CGW1A499B28Z 1 *
P4 963411002810S 4KEY BUTTON BK CBT1A1138B28 2
P4 963411002930S 4KEY BUTTON SP CBT1A1138G45 2
P5 963411001410D 3KEYB BUTTON BK CBT1A1139B28Z 1
P5 963411011340D 3KEYB BUTTON SP CBT1A1139G45Z 1
P6 00D9630365002 WINE 3KEY BUTTON BK CBT1A1140B28 2
P6 00D9630365301 WINE 3KEY BUTTON SP CBT1A1140G45 2
P7 nsp FOOT CUSHION CHG2A289 4
P8 943416009700D FOOT CKL2A093 4
P9 943407009710D FL WINDOW CGU1A451Z 1
P10 943411009860D BUTTON STANDBY ASS'Y BK CBT1A1141ZA 1 *
P10 943411009870D BUTTON STANDBY ASS'Y SP CBT1A1141YA 1 *
P11 00D9630137807 STANDBY LENS CGL1A289 1
P12 nsp RUBBER CHG1A113 1
s
s
s

Denon AVR-391 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Dolby Formats	Dolby Digital, Dolby Pro Logic II
Audio Return Channel	Yes
Component Video Inputs	2
Digital Optical Inputs	1
Digital Coaxial Inputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Power Output	75 Watts per channel
DTS Formats	DTS
Tuner Frequency Range	FM: 87.5 - 108 MHz
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Dimensions	434 x 151 x 319 mm
Weight	8.5 kg
