Denon AVR-391 Service Manual

64
Ref.No. Part No. Part Name Remarks Q'ty New
P13 nsp PCB HOLDER CHE170 2
M1 nsp TOP BRACKET CMD1A355 2
M2 nsp BOTTOM CHASSIS CUA4A302 1
M3 nsp PCB BRACKET CMD1A417 2
M4 nsp PCB BRACKET CMD1A774 2
M5 nsp REAR PANEL 1311SPE2,1311BKE2 CKF4A437Z 1 *
M5 nsp REAR PANEL 1311SPE1C CKF3A437Y 1 *
M5 nsp REAR PANEL 391BKE3 CKF1A437Z 1 *
M5 nsp REAR PANEL 391BKEA CKF1A437Y 1 *
M5 nsp REAR PANEL 391BKE3B CKF1A437X 1 *
M6 00D1310158007 DENON BADGE(BLACK049) BK CGB1A140U 1
M6 00D1310158010 DENON BADGE(SILVER052) SP CGB1A140T 1
M7 nsp FIP BRACKET CMD1A572 2
M8 00M07BW257010 TOP CABINET BK CKC2A155K117 1
M8 943403002040M TOP CABINET SP CKC1A155D11 1
M9 nsp HEAT SINK CMY8A161 1
M10 nsp TRANS BRACKET CMD2A675 1
M11 nsp PCB BRACKET CMD1A569 4
M12 nsp PCB BRACKET CMD1A188 1
C12 943252010310S POSISTOR ASS'Y (100) CRTDHTS100180W 1
z
C14 943101009650D POWER TRANS
1311SPE2,1311BKE2,
391BKEA
CLT5U042ZE 1 *
z
C14 943101009660D POWER TRANS 1311SPE1C CLT5U042ZH 1 *
z
C14 943101009640D POWER TRANS 391BKE3,391BKE3B CLT5U042ZU 1 *
C15 nsp CORD BUSHING KHR1A028 1
C16 00MYJ04002640 AC RECEPTACLE(15A/250V,R-301,B21) 1311BKE2,1311SPE2 CJJ8A006ZW
★
H1 nsp WIRE ASS'Y 2P(100MM) 1311SPE2,1311BKE2 CWZPM5003TW91A 1
★
H2 943606009880D CARD CABLE CWC4C4A13B120B 1 *
★
H3 943606009890D CARD CABLE(Shield,105C)
CWC4C4A23B220B08S 1*
★
H4 943606009900D CARD CABLE CWC6C4A19B100B10 1 *
★
H5 nsp FERRITE RING CLZ9W003Z 1
★
H6 nsp FERRITE CORE RINGTYPE CLZ9Z004Y 1
★
H7 nsp FERRITE CORE CLZ9Z071Z 1
★
H8 nsp CLAMPER CHR301 7
★
H9 nsp TAPE HEMELON CHS1A032 3
★
H10 606050028012P (7)P FFC(1.0) 606050028012P 1
SCREWS
S1 nsp SPECIAL SCREW CHD1A012R 17
S2 nsp SCREW CTWS3+10GR 2
S3 nsp SCREW CTB3+6JR 18
S4 nsp SCREW CTBD3+10JR 23
S5 nsp SCREW
1311BKE2,1311SPE2,
1311SPE1C
CTBD3+8JFZR 19
S5 nsp SCREW 391BKE3,391BKE3B,391BKEA CTBD3+8JFZR 17
S6 nsp SCREW BK CTWD4+6FFZR 6
S6 nsp SCREW SP CTWD4+6FFN 6
S7 nsp SCREW CTB3+6FFZR 12
S8 nsp SCREW CTW3+8JR 15
s
s
s

Denon AVR-391 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Dolby Formats	Dolby Digital, Dolby Pro Logic II
Audio Return Channel	Yes
Component Video Inputs	2
Digital Optical Inputs	1
Digital Coaxial Inputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Power Output	75 Watts per channel
DTS Formats	DTS
Tuner Frequency Range	FM: 87.5 - 108 MHz
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Dimensions	434 x 151 x 319 mm
Weight	8.5 kg
