12
(3) Remove the RADIATOR ASSY from the main unit.
5. POWER UNIT
6. POWER TRANS
Direction of photograph: C
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in RADIATOR ASSY.
TOP
COVER
POWER UNIT
→
Proceeding :
Please refer to "EXPLODED VIEW" for the disassembly method of POWER UNIT.
CABINET TOP
TRANS MAIN
→
Proceeding :
Please refer to "EXPLODED VIEW" for the disassembly method of POWER TRANS.
