Denon AVR-391 Service Manual

91
Ref. No. Part No. Part Name Remarks Q'ty New
CN207 nsp LOCKINGTYPE STRAIGHTWAFER 2mm CJP05GI236ZW
CN208 nsp WAFER STRAIGHT CJP05GA19ZY
CN209 nsp WAFER ANGLE(2.5mm) CJP05GB03ZY
z
F201 943652000620S FUSE(0.1A 372SERIES/TR5) CBA2D0100A3EYT
FL201 943172010110S VFD HCA-18SM01T CFLHCA18SM01T *
GND21,22 nsp PCB BRACKET CMD1A569
JK201 90M-YT004310R JACK BOARD(3P) CJJ4S041Z
JK202 943643010130S JACK CJJ2E020Z *
JK204 943643010140S JACK HEADPHONE(3.5mm GOLD) CJJ2E028Z *
L201-206 nsp CHIP FERRITE BEAD(60ohm 1608) CLZ9R005Z
LUG21 nsp WIRE ASS'Y(1P) CWE8102080RV
LUG22 nsp WIRE ASS'Y CWE8202100RV
LUG24 nsp WIRE ASS'Y CWE8102100RV
LUG25 nsp WIRE ASS'Y CWE8102150RV
LUG26 nsp WIRE ASS'Y(1P) CWE8202080RV
RC201 943262010290S REMOCON SENSOR CRVKSM603TH5B
SW201-218 00D9430004402 TACT SW CST1A012ZT

Denon AVR-391 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Dolby Formats	Dolby Digital, Dolby Pro Logic II
Audio Return Channel	Yes
Component Video Inputs	2
Digital Optical Inputs	1
Digital Coaxial Inputs	1
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Power Output	75 Watts per channel
DTS Formats	DTS
Tuner Frequency Range	FM: 87.5 - 108 MHz
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Dimensions	434 x 151 x 319 mm
Weight	8.5 kg
