PACKING VIEW
PARTS LIST OF PACKING & ACCESSORIES
z
Parts indicated by "nsp" on this table cannot be supplied.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China mode JP : Japan model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
L20 nsp MAC ADDRESS SUB ASSY
L70 nsp CONT LABEL SUB ASSY
P10 nsp CABINET SHEET 1
P20 53111024101AD CARTON CASE BKE2 1
P20 53111024100AD CARTON CASE CIBKE3 1
P20 53111024103AD CARTON CASE K 1
P20 53111024102AD CARTON CASE SPE1C 1
P20 53111024101AD CARTON CASE SPE2 1
P30 nsp SPACER 2
P40 nsp CUSHON ASSY 1
U10 nsp ENVELOPE BKE2 1
P40
P40
P10
L20
U130
L70
U10 U20 U25 U30 U40 U80U70U60U50
U90
P20
P30
U75
U110
U120
U130
