Specifications - Video section, Tuner
HOME
Video section
Standard video connectors
Input/output level and impedance 1 Vp-p, 75 Ω/ohms
Frequency response
5 Hz -10MHz, 0, - 3dB (when “Video Conversion”
set to “Off”)
Color component video connector
Input/output level and impedance
Y signal 1 Vp-p, 75 Ω/ohms
PB/CB signal 0.7 Vp-p, 75 Ω/ohms
PR/CR signal 0.7 Vp-p, 75 Ω/ohms
Frequency response 5 Hz - 60MHz – 0, -3dB
Tuner section
FM AM
Note: µV at 75 Ω/ohms, 0 dBf = 1x10
-15
W
Reception frequency range 87.50 MHz - 107.90 MHz 530 KHz - 1710 KHz
Effective sensitivity 1.5 µV (14.8 dBf) 20µV
S/N ratio (IHF-A)
Mono 78 dB
85dBStereo 68 dB
HD 85 dB
Distortion (1 KHz)
Mono 0.1 %
0.02 %Stereo 0.2 %
HD 0.02 %
SPECIFICATIONS - VIDEO –
TUNER
SPECIFICATIONS -
AUDIO
SPECIFICATIONS -
DIMENSIONS - WEIGHT
SPECIFICATIONS
SWITCHING HUB -
GENERAL
15
