Rear Panel
HOME
USB port
TRIGGER OUT jacks
REMOTE CONTROL jacks
Speaker terminals
(SPEAKERS)
RS-232C connector
SIGNAL GND terminal
PRE OUT connectors
Video connectors (VIDEO)
AC inlet (AC IN)
Component video connectors
(COMPONENT VIDEO)
EXTERNAL IN connectors
HDMI connectors
Analog audio connectors
(AUDIO)
FM/AM antenna terminals (ANTENNA)
Denon Link HD connector
Digital audio connectors
(DIGITAL AUDIO)
Network connectors (NETWORK)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit
