43
AVR-1706/686/1506/486
LED309 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED310 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED311 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
FL301 00D 963 0219 806 DISPLAY,FLT 16-ST-82GNK
RESISTORS GROUP
R211 00D 960 9003 807 R,METAL FILM 100-J,1/4W
R271 00D 963 0215 907 R,METAL FILM 4.7-J,1W For AVR1706E2/EUT,1506/486E3
R272 00D 963 0215 907 R,METAL FILM 4.7-J,1W For AVR1706/686E3
CAPACITORS GROUP
C201 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C202 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C203 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C204 00D 960 9010 764 C,ELECT 4.7UF-M/50V
C205 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C206 00D 963 9005 862 C,ELECT 47UF-M/16V For AVR1706E2
C207 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V For AVR1706E2
C208 nsp 00D 963 0223 708 C,CERAMIC CHIP 270PF-J/50V For AVR1706E2
C209 00D 963 0234 205 C,ELECT 10UF-M/50V For AVR1706E2
C210 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V For AVR1706E2
C211 nsp 00D 963 9004 614 C,CERAMIC CHIP 27PF-J/50V For AVR1706E2
C212 nsp 00D 963 9004 614 C,CERAMIC CHIP 27PF-J/50V For AVR1706E2
C221 00D 960 9009 911 C,ELECT 100UF-M/10V
C261 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C262 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C267 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C268 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C269 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C270 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C271 00D 963 0234 205 C,ELECT 10UF-M/50V For AVR1706E2/EUT,1506/486E3
C272 00D 963 0234 205 C,ELECT 10UF-M/50V For AVR1706E2/EUT,1506/486E3
C273 00D 963 0234 205 C,ELECT 10UF-M/50V For AVR1706/686E3
C274 00D 963 0234 205 C,ELECT 10UF-M/50V For AVR1706/686E3
C275 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C276 00D 963 0234 205 C,ELECT 10UF-M/50V For AVR1706/686E3
C277 00D 963 0234 205 C,ELECT 10UF-M/50V For AVR1706/686E3
C278 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C291 00D 963 9004 517 C,CERAMIC 0.022UF-Z/50V
C292 00D 963 9004 517 C,CERAMIC 0.022UF-Z/50V
C293 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C294 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C295 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C301 00D 963 0234 205 C,ELECT 10UF-M/50V
C302 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C303 00D 963 9005 862 C,ELECT 47UF-M/16V
C304 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V
C305 00D 963 9005 862 C,ELECT 47UF-M/16V
C306 00D 963 0216 401 C,FILM 0.1UF-J/100V
C307 00D 963 9005 749 C,ELECT 1UF-M/50V
C308 00D 963 0021 900 C,FILM 0.047UF-J/100V
C309 00D 963 0021 900 C,FILM 0.047UF-J/100V
C310 00D 963 9005 749 C,ELECT 1UF-M/50V
C311 nsp 00D 963 0233 701 C,CERAMIC CHIP 30PF-J/50V
C312 00D 963 9005 859 C,ELECT 47UF-M/16V
C313 00D 963 0216 702 C,FILM 0.047UF-J/63V
C314 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V
C321 nsp 00D 963 0224 105 C,CERAMIC CHIP 1000PF-K/50V
C322 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C324 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C325 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
Ref. No. nsp Part No. Part Name Remarks Q'ty New
