AVR-1706/686/1506/486
PARTS LIST OF EXPLODED VIEW (for AVR-1706/686 model)
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
＊"nsp" 印の部品は常時在庫していませんので供給に長時間を要することがあります。場合によっては、供給をお断りする場合があります。
＊ Part indicated with the mark “nsp” are not always in stock and possibly to take a long period of time for supplying, or in some case supplying of part may be refused.
Note: The symbols in the column "Remarks" indicate the following destinations.
AVR1706 model E3 : U.S.A. & Canada model E2 : Europe model EUT : Taiwan R.O.C. model
AVR686 model E3 : U.S.A. & Canada model (AVR686)
Ref. No. nsp Part No. Part Name Remarks Q'ty New
43A nsp 00D 963 0250 205 MAIN P.W.B. Ass'y for E3 1 *
43A nsp 00D 963 0250 807 MAIN P.W.B. Ass'y for E2 1 *
43A nsp 00D 963 0251 301 MAIN P.W.B. Ass'y for EUT 1 *
43A nsp 00D 963 0250 205 MAIN P.W.B. Ass'y for AVR686 1 *
14 - HEADPHONE P.W.B.
20 - TACT SW P.W.B.
43 - MAIN P.W.B.
47 - AC OUTLET P.W.B.
60A nsp 00D 963 0250 302 CPU P.W.B. Ass'y for E3 1 *
60A nsp 00D 963 0250 904 CPU P.W.B. Ass'y for E2 1 *
60A nsp 00D 963 0251 408 CPU P.W.B. Ass'y for EUT 1 *
60A nsp 00D 963 0250 302 CPU P.W.B. Ass'y for AVR686 1 *
15 - POWER SW P.W.B.
21 - FRONT P.W.B.
25 - V-AUX P.W.B.
60 - CPU P.W.B.
59A nsp 00D 963 0250 409 CNT P.W.B. Ass'y for E3 1 *
59A nsp 00D 963 0251 000 CNT P.W.B. Ass'y for E2 1 *
59A nsp 00D 963 0251 505 CNT P.W.B. Ass'y for EUT 1 *
59A nsp 00D 963 0251 709 CNT P.W.B. Ass'y for AVR686 1 *
35 - 2CH-AMP P.W.B.
45 - PRE AMP P.W.B.
59 - CNT P.W.B.
69 - 6CH-EXT P.W.B.
66A nsp 00D 963 0250 506 INPUT P.W.B. Ass'y for E3 1 *
66A nsp 00D 963 0251 107 INPUT P.W.B. Ass'y for E2 1 *
66A nsp 00D 963 0251 602 INPUT P.W.B. Ass'y for EUT 1 *
66A nsp 00D 963 0250 506 INPUT P.W.B. Ass'y for AVR686 1 *
66 - INPUT P.W.B.
78 - MIC P.W.B.
64A nsp 00D 963 0250 603 C-S VIDEO 1 P.W.B. Ass'y for E3 1 *
64A nsp 00D 963 0251 204 C-S VIDEO 2 P.W.B. Ass'y for E2 1 *
64A nsp 00D 963 0251 204 C-S VIDEO 2 P.W.B. Ass'y for EUT 1 *
64A nsp 00D 963 0250 603 C-S VIDEO 1 P.W.B. Ass'y for AVR686 1 *
61 - COMP-V P.W.B.
62 - V-CNT DOWN P.W.B.
63 - V-CNT UP P.W.B.
64 - C-S VIDEO P.W.B.
65A 00D 963 0250 700 DSP P.W.B. Ass'y for E3 1 *
65A 00D 963 0250 700 DSP P.W.B. Ass'y for E2 1 *
65A 00D 963 0250 700 DSP P.W.B. Ass'y for EUT 1 *
65A 00D 963 0250 700 DSP P.W.B. Ass'y for AVR686 1 *
65 - DSP P.W.B.
