Page #49 background imageLoading...
Page #49 background image
49
AVR-1706/686/1506/486
C505SBR 00D 963 0216 100 C,CERAMIC 33PF-J/500V
C505SL 00D 963 0216 100 C,CERAMIC 33PF-J/500V
C505SR 00D 963 0216 100 C,CERAMIC 33PF-J/500V
C506C 00D 960 9009 911 C,ELECT 100UF-M/10V
C506FL 00D 960 9009 911 C,ELECT 100UF-M/10V
C506FR 00D 960 9009 911 C,ELECT 100UF-M/10V
C506SBL 00D 960 9009 911 C,ELECT 100UF-M/10V
C506SBR 00D 960 9009 911 C,ELECT 100UF-M/10V
C506SL 00D 960 9009 911 C,ELECT 100UF-M/10V
C506SR 00D 960 9009 911 C,ELECT 100UF-M/10V
C507C 00D 963 9003 194 C,FILM 0.0022UF-J/100V
C507FL 00D 963 9003 194 C,FILM 0.0022UF-J/100V
C507FR 00D 963 9003 194 C,FILM 0.0022UF-J/100V
C507SBL 00D 963 9003 194 C,FILM 0.0022UF-J/100V
C507SBR 00D 963 9003 194 C,FILM 0.0022UF-J/100V
C507SL 00D 963 9003 194 C,FILM 0.0022UF-J/100V
C507SR 00D 963 9003 194 C,FILM 0.0022UF-J/100V
C551 00D 963 9006 117 C,ELECT 2.2UF-M/50V
C551S 00D 963 0225 609 C,CERAMIC 0.047UF-Z/50V
C555 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C556 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C557 00D 963 0234 205 C,ELECT 10UF-M/50V
C559 00D 963 0145 006 C,FILM 0.047UF-J/50V For AVR1706/686E3
C560 00D 963 0145 006 C,FILM 0.047UF-J/50V For AVR1706/686E3
C561 00D 963 0145 006 C,FILM 0.047UF-J/50V For AVR1706/686E3
C563X 00D 963 0234 205 C,ELECT 10UF-M/50V
C564X nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C565X 00D 963 0234 205 C,ELECT 10UF-M/50V
C566X nsp 00D 960 9010 094 C,CERAMIC CHIP 0.01UF-Z/50V
C567X nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C568X nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C569X nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C570X nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
OTHER PARTS GROUP
BD401 00D 963 0154 602 BEAD,COIL
BD402 00D 963 0154 602 BEAD,COIL
BD403 00D 963 0154 602 BEAD,COIL For AVR1706/1506E3
CN402 nsp 00D 960 0239 900 CN.WAFER 13P
CN501 nsp 00D 963 0085 506 CN.WAFER 9P
CN502 nsp 00D 963 0086 505 CN.WAFER 7P
CN503 nsp 00D 963 0205 700 CN.WAFER 5P
CN504 nsp 00D 963 0205 700 CN.WAFER 5P
CN505 nsp 00D 963 0236 902 CN.WAFER 12P
CN552 nsp 00D 963 0097 303 CN.WAFER 15P
CN553 nsp 00D 963 0086 709 CN.WAFER 11P
CN554A nsp 00D 963 0184 805 CN,WIRE 80MM/14P
CN554B nsp 00D 963 0184 708 CN,WIRE 80MM/4P
CN555 nsp 00D 963 0110 701 CN.WAFER 14P
CN556 nsp 00D 963 0086 709 CN.WAFER 11P
CN557 nsp 00D 963 0253 105 CN,WIRE 110MM/15P *
CN992 nsp 00D 960 0217 553 CN.WAFER 4P
CP401 nsp 00D 963 0097 303 CN.WAFER 15P
CP401A nsp 00D 963 0149 303 CN.FPC 15P
CP551 nsp 00D 963 0253 406 CN.WAFER 14P *
CP554A nsp 00D 963 0253 406 CN.WAFER 14P *
CP554B nsp 00D 963 0235 903 CN.WAFER 4P
CP557 nsp 00D 963 0107 206 CN.WAFER 15P
CP590 nsp 00D 963 0236 009 CN.WAFER 3P For AVR1706/686E3
L101SBL 00D 963 0049 005 COIL,INDUCTOR 0.5UH
L101SBR 00D 963 0049 005 COIL,INDUCTOR 0.5UH
