Page #59 background imageLoading...
Page #59 background image
59
AVR-1706/686/1506/486
C625 00D 963 9005 901 C,ELECT 470UF-M/10V
C626 00D 963 9005 862 C,ELECT 47UF-M/16V
C627 00D 963 9005 862 C,ELECT 47UF-M/16V
C628 00D 963 9005 862 C,ELECT 47UF-M/16V
C629 00D 963 9005 901 C,ELECT 470UF-M/10V
C630 00D 963 9005 901 C,ELECT 470UF-M/10V
C632 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C633 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C634 00D 963 9005 749 C,ELECT 1UF-M/50V
C635 00D 963 9005 749 C,ELECT 1UF-M/50V
C651 00D 960 9010 010 C,ELECT 4.7UF-M/50V For AVR1506/486E3
C651R 00D 963 9005 778 C,ELECT 10UF-M/50V For AVR1706E2,EUT
C652 00D 960 9010 010 C,ELECT 4.7UF-M/50V For AVR1506/486E3
C652R 00D 963 9005 778 C,ELECT 10UF-M/50V For AVR1706E2,EUT
C653 00D 960 9010 010 C,ELECT 4.7UF-M/50V For AVR1506/486E3
C653R 00D 963 0234 506 C,ELECT 47UF-M/50V For AVR1706E2,EUT
C654 00D 960 9010 010 C,ELECT 4.7UF-M/50V For AVR1506/486E3
C655 00D 960 9010 010 C,ELECT 4.7UF-M/50V For AVR1506/486E3
C656 00D 960 9010 010 C,ELECT 4.7UF-M/50V For AVR1506/486E3
C657 00D 963 9005 969 C,ELECT 4700UF-M/6.3V For AVR1506/486E3
C658 00D 963 9006 036 C,ELECT 470UF-M/6.3V For AVR1506/486E3
C659 00D 963 9006 036 C,ELECT 470UF-M/6.3V For AVR1506/486E3
C660 00D 960 9009 911 C,ELECT 100UF-M/10V For AVR1506/486E3
C661 00D 960 9009 911 C,ELECT 100UF-M/10V For AVR1506/486E3
C662 00D 960 9009 911 C,ELECT 100UF-M/10V For AVR1506/486E3
C663 00D 960 9010 010 C,ELECT 4.7UF-M/50V For AVR1506/486E3
C664 00D 960 9010 010 C,ELECT 4.7UF-M/50V For AVR1506/486E3
C665 00D 960 9010 010 C,ELECT 4.7UF-M/50V For AVR1506/486E3
C671 00D 963 9005 749 C,ELECT 1UF-M/50V For AVR1506/486E3
C672 00D 963 9005 749 C,ELECT 1UF-M/50V For AVR1506/486E3
C673 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V For AVR1506/486E3
C674 00D 960 9009 911 C,ELECT 100UF-M/10V For AVR1506/486E3
C674A 00D 963 0234 506 C,ELECT 47UF-M/50V For AVR1506/486E3
C681 00D 963 9005 749 C,ELECT 1UF-M/50V For AVR1506/486E3
C682 00D 963 9005 749 C,ELECT 1UF-M/50V For AVR1506/486E3
C683 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V For AVR1506/486E3
C691 00D 963 9005 749 C,ELECT 1UF-M/50V For AVR1506/486E3
C692 00D 963 9005 749 C,ELECT 1UF-M/50V For AVR1506/486E3
C693 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V For AVR1506/486E3
C695 00D 963 9005 778 C,ELECT 10UF-M/50V For AVR1506/486E3
C696 00D 963 9005 778 C,ELECT 10UF-M/50V For AVR1506/486E3
OTHER PARTS GROUP
CN601 nsp 00D 963 0236 902 CN.WAFER 12P
CN603 nsp 00D 963 0097 206 CN.WAFER 8P
CN604 nsp 00D 963 0097 206 CN.WAFER 8P
CN605 nsp 00D 963 0097 206 CN.WAFER 8P
CP603 nsp 00D 963 0097 400 CN.WAFER 8P
CP604 nsp 00D 963 0097 400 CN.WAFER 8P
CP605 nsp 00D 963 0097 400 CN.WAFER 8P
RLY651 00D 963 0218 302 RELAY BC3-6 For AVR1706E2,EUT
RLY652 00D 963 0218 302 RELAY BC3-6 For AVR1706E2,EUT
RLY653 00D 963 0218 302 RELAY BC3-6 For AVR1706E2,EUT
RLY654 00D 963 0218 302 RELAY BC3-6 For AVR1706E2,EUT
RLY655 00D 963 0218 302 RELAY BC3-6 For AVR1706E2,EUT
RLY656 00D 963 0218 302 RELAY BC3-6 For AVR1706E2,EUT
00D 963 0146 005 TER,RCA 1PIN
00D 963 0218 001 TER,RCA 2PIN
00D 963 0218 108 TER,RCA 3PIN
00D 963 0146 306 TER,RCA 6PIN
-HEAT SINK
Ref. No. nsp Part No. Part Name Remarks Q'ty New
