Denon AVR-5308CI Service Manual

125
AVR-5308CI / AVC-A1HD
1U-3819 ETHERNET P.W.B. UNIT ASS'Y(EU model)
1U-3819A ETHERNET P.W.B. UNIT ASS'Y(E2,JP model)
(This P.W.B. UNIT is replaced by ASS’Y level.)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 nsp RTL8201CP
IC102 nsp FSUSB22
IC103,104 nsp FDC608PZ
IC105 nsp BCOIC-DM850E-CQL
IC106 nsp
ETHER ROM
ASSY(S29GL064A90TFIR40)
for EU : 00DGEN8537
IC106 nsp
ETHER ROM
ASSY(S29GL064A90TFIR40)
for E2,JP : 00DGEN8537A
IC107 nsp W9812G6GH-6
IC108 nsp FCX0-03(24.576MHZ) +REF
IC109 nsp SN74LVC2G32DCT
IC110 nsp SN74LVC2G14DBVR
IC111,112 nsp MICROSMD175F
IC401 nsp F2621E-01 for EU
IC402 nsp LC89057W-VF4A for EU
IC403 nsp PQ033DNA1ZPH for EU
IC404 nsp SAA7121H
IC405 nsp UPC2933BT1D-E1-AT
IC406 nsp EN5312QI-T
IC410 nsp TC7W66FK
IC411 nsp SN74LV594APWR
TR101-104 nsp KRC102S-RTK/P (10K-10K)
TR107 nsp KRC104S-RTK/P (47K-47K)
TR108 nsp KRA102S-RTK/P (10K-10K)
TR111-113 nsp KRC102S-RTK/P (10K-10K)
TR401 nsp KRC102S-RTK/P (10K-10K)
TR912 nsp 2SB1412TL(PQR) +C
TR913 nsp KRC102S-RTK/P (10K-10K)
D101-104 nsp ESD PROTECTOR(6802)
D401 nsp RB521S-30TE61 +REF
D403,404 nsp RB521S-30TE61 +REF
D406-408 nsp ESD PROTECTOR(6802)
ZD401 nsp NSAD500F-T1B
RESISTORS GROUP
R198 nsp RM73B--5491DT(1608)
R401,402 nsp RM73B20R0KT +3216
R487 nsp RM73B--104DT(1608)
CAPACITORS GROUP
C101 nsp CK73B1H102KT +1005
C103 nsp CK73B1H102KT +1005
C105,106 nsp CK73B1A104KT +1005
C107,108 nsp CK73B1E104KT +1608
C109 nsp CK73B1A104KT +1005
C110 nsp CE67C0J101MT+REF
C111-115 nsp CK73B1A104KT +1005
C116-118 nsp CK73B1H102KT +1005
C119 nsp CK73B0J475KT(P) +1608
C120 nsp CK73B1H102KT +1005
C121-123 nsp CK73B1A104KT +1005
C126,127 nsp CK73B1A104KT +1005
C130 nsp CS77B1A100MT(NOJ)
C131 nsp CK73B1H102KT +1005
ファームウエアをアップデート
するときは、SDI で最終バージョ
ンを確認して下さい。
サービス基板はアップデートし
て使用下さい。
WhenupdateFirmware,please
confirmalastversioninSDI.
Usetheserviceboardafter
updatingit.
