AVR-5308CI / AVC-A1HD
1U-3825 FRONT POWER P.W.B. UNIT ASS'Y(EU model)
1U-3825A FRONT P.W.B. UNIT ASS'Y(E2 model)
1U-3825C FRONT P.W.B. UNIT ASS'Y(JP model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
z IC101 00D2680073905 ICP-N15T
IC104,105 00D2631223005 PQ20RX11J00H
IC106 00D2631242918 NJM2831F06
IC701 00D4990318002 GP1UM271XKVF
TR101 00D2730480901 KTC2025D-Y-RTF/P
TR102 00D2730464901 KTC3875S-GR-RTK/P
TR103-105 00D2690192902 KRC102S-RTK/P (10K-10K)
TR701 00D2690192902 KRC102S-RTK/P (10K-10K)
TR702,703 00D2710312905 KTA1504S-GR-RTK/P
TR704 00D2690193901 KRC104S-RTK/P (47K-47K)
TR705 00D2690191903 KRA104S-RTK/P (47K-47K)
TR707-709 00D2740212907 2SD1782KT146
TR710-713 00D2690192902 KRC102S-RTK/P (10K-10K)
D101-108 00D2760704903 1SR35-400A(T93X)
D109 00D2760305001 S4VB20
D110 00D2760773905 RB501V-40 +2125
D111-113 00D2760704903 1SR35-400A(T93X)
D114,115 00D2760773905 RB501V-40 +2125
D116,117 00D2760704903 1SR35-400A(T93X)
D119 00D2760704916 1SR35-400A(T82)
ZD101,102 00D2760480900 HZS22-1TD
ZD103,104 00D2760455906 HZS4A-1TD
ZD105 00D2760464900 HZS7A-1TD
ZD106 00D2760683956 UDZS15B-TE17 +C
LD701 00D3939671002 SMLU12416W-S
LD702-704 00D3939452904 SEL1410E(TP2)
FL701 00D3938094004 FLD(19-BT-08GINK)
RESISTORS GROUP
R116 00D2470046951 RM73B--202DT
R118 00D2470046951 RM73B--202DT
CAPACITORS GROUP
C101,102 00D2551279951 CQ93M1H104JT(B)
C103 nsp CK73B1E104KT +1608
C104,105 00D2544540710 CE04W1J471MC SMG/RE3
C106 nsp CK73B1E104KT +1608
C107 00D2544527940 CE04W2A010MT SMG/RE3
C108,109 nsp CK73B1E104KT +1608
C110 00D2544396906 CE04W1J101MT(SMG)
C111 nsp CK73B1E104KT +1608
C112 00D2544524985 CE04W1H100MT SMG/RE3
C113 nsp CC73CH1H102JT +1608
C114 00D2544524943 CE04W1H010MT SMG/RE3
C115,116 00D2554256955 CQ93P2A103JT(NH2)
C117 nsp CC73CH1H102JT +1608
C118 00D2544524943 CE04W1H010MT SMG/RE3
C119,120 00D2544803703 CE04W1E472MC(SMQL25S
C121 00D2544524943 CE04W1H010MT SMG/RE3
C123 00D2544803703 CE04W1E472MC(SMQL25S
C124-126 00D2544524985 CE04W1H100MT SMG/RE3
C127-129 00D2544538939 CE04W1C470MT SMG/RE3
C165,166 nsp CC73CH1H221JT +1608
