AVR-5308CI / AVC-A1HD
PACKING VIEW
PARTS LIST OF PACKING & ACCESSORIES
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
EU : U.S.A. model(AVR-5308CI) E2 : Europe model(AVC-A1HD) JP : Japan model(AVC-A1HD)
Ref. No. Part No. Part Name Remarks Q'ty New
201 00D5040192106 CABINET SHEET 1
202 00D5031547003 CUSHION ASSY 1 *
203 00D5012262006 PAD 1 *
204 539210001001D SPACER 2 *
205 00D5012367008 CARTON CASE(EU) for EU 1 *
205 00D5012367024 CARTON CASE(E2) for E2 1 *
205 00D5012367040 CARTON CASE(JP) for JP 1 *
206 nsp COLOR LABEL for E2 1
207 nsp GUARANTEE CARD (S) for JP 1
209 nsp CONT.CARD(L)SUB ASSY 1
210 nsp BAR CODE LABEL ASSY 1
220 nsp ENVELOPE 1
221 00D5114613003 INST. MANUAL (EU) for EU 1 *
221 00D5114671003 INST. MANUAL (E2) for E2 1 *
221 00D5114677007 INST. MANUAL (JP) for JP 1 *
222 00D5114289068 INST.MANUAL(E2/CDROM) for E2 1 *
