AVR-5308CI / AVC-A1HD
BU4094BCFV-E2 (CPU: IC801,802,903,904)
(A.VIDEO: IC713,714,715,716,717)
(A.AUDIO: IC501,502,503,505)
BU4094BCFV-E2 Terminal Function
Extended IC PRE MUTE/RELAY/TRIGGER Signal Control
Used Port : FPREEXP DATA(P33),CLK(P32),OE(P35),STB(P34)
Part Name Pin Name Symbol Function
1U-3821
IC903
EXP1 (RST SUB) Not used
EXP2 USER1 LED USER 1 LED control pin (ON : H)
EXP3 USER2 LED USER 2 LED control pin (ON : H)
EXP4 USER3 LED USER 3 LED control pin (ON : H)
EXP5 FAN LOW FAN control pin
EXP6 FAN ON FAN control pin
EXP7 TRIGGER 1 TRIGGER OUT 1 control pin
EXP8 TRIGGER 2 TRIGGER OUT 2 control pin
1U-3821
IC904
EXP9 TRIGGER 3 TRIGGER OUT 3 control pin
EXP10 TRIGGER 4 TRIGGER OUT 4 control pin
EXP11 GUI RST GUI control pin
EXP12 ZONE2 OSD RST ZONE2 OSD control pin
EXP13 USB SEL USB FRONT/BACK SELECT control pin
EXP14 USB EN USB SELECT control pin (Normal :L, FRONT/REAR SELECT switching=1s : H)
EXP15 NC Not used
EXP16 (RDS TEST) PRODUCT MODE (RDS receive : L)
1U-3823
IC701
EXP17 PRE RL FL PRE OUT RELAY control
EXP18 PRE RL FR PRE OUT RELAY control
EXP19 PRE RL C PRE OUT RELAY control
EXP20 PRE RL SW1 PRE OUT RELAY control
EXP21 PRE RL SL PRE OUT RELAY control
EXP22 PRE RL SR PRE OUT RELAY control
EXP23 PRE RL SBL PRE OUT RELAY control
EXP24 PRE RL SBR PRE OUT RELAY control
1U-3823
IC703
EXP25 PRE RL SL B PRE OUT RELAY control
EXP26 PRE RL SR B PRE OUT RELAY control
EXP27 PRE RL SW2 PRE OUT RELAY control
EXP28 PRE RL SW3 PRE OUT RELAY control
EXP29 PRE RL Z2 PRE OUT RELAY control
EXP30 PRE RL Z3 PRE OUT RELAY control
EXP31 SP RL ZR B SP OUT RELAY control
EXP32 SP RL FR C SP OUT RELAY control
1U-3823
IC705
EXP33 SP RL FL SP OUT RELAY control
EXP34 SP RL SL SP OUT RELAY control
EXP35 SP RL FR SP OUT RELAY control
EXP36 SP RL C SP OUT RELAY control
EXP37 SP RL SBL SP OUT RELAY control
EXP38 SP RL FLB SP OUT RELAY control
EXP39 SP RL SR SP OUT RELAY control
EXP40 SP RL SBR SP OUT RELAY control
STROBE 1
2
3
4
5
6
7
8
9
10
11
16
15
14
13
12
DATA
CLOCK
Q1
Q2
Q3
Q4
V
SS
V
DD
OE
Q5
Q6
Q7
Q8
Q’
S
Q
S
