Denon AVR-5308CI - Page 82

82
AVR-5308CI / AVC-A1HD
Extended IC VIDEO Signal Control
Used Port : V.EXP DATA(P17),CLK(P20),OE(P21),STB(P22)
1U-3823
IC702
EXP41 SP RL SLB SP OUT RELAY control
EXP42 (SP RL ZL) Not used
EXP43 SP RL FRB SP OUT RELAY control
EXP44 SP RL SRB SP OUT RELAY control
EXP45 SP RL FL C SP OUT RELAY control
EXP46 SP RL ZL B SP OUT RELAY control
EXP47 (SP RL ZR) Not used
EXP48 H/P RL H/P RELAY control pin
1U-3823
IC704
EXP49 NC NC
EXP50 NC NC
EXP51 NC NC
EXP52 NC NC
EXP53 NC NC
EXP54 NC NC
EXP55 NC NC
EXP56 NC NC
1U-3823
IC706
EXP57 NC NC
EXP58 NC NC
EXP59 NC NC
EXP60 NC NC
EXP61 NC NC
EXP62 NC NC
EXP63 NC NC
EXP64 NC NC
Part Name Pin Name Symbol Function
1U-3821
IC801
EXP1 HPD1 HDMI IN1 pin, HP DET control pin
EXP2 HPD2 HDMI IN2 pin, HP DET control pin
EXP3 HPD3 HDMI IN3 pin, HP DET control pin
EXP4 HPD4 HDMI IN4 pin, HP DET control pin
EXP5 HPD5 HDMI IN5 pin, HP DET control pin
EXP6 HPD6 HDMI IN6 pin, HP DET control pin
EXP7 REALTA MODE
Normal : H, Write for REALTA : L
→ H
EXP8 SUP MODE Normal : H, Output for expander control : L
1U-3821
IC802
EXP9 DSD ON DSD signal input : H
EXP10 REALTA WRITE Normal : H,Write for REALRA ROM : L
EXP11 (VIDEO TEST) Not used
EXP12 NC NC
EXP13 NC NC
EXP14 NC NC
EXP15 NC NC
EXP16 NC NC
1U-3822
IC103
EXP17 Z1 P.SAVE
MAIN ZONE COMPONENT
→ CONVERTroute DISABLE pin
EXP18 Z2 P.SAVE
ZONE2 COMPONENT
→ CONVERTroute DISABLE pin
EXP19 Z1 MONIDIS MAIN ZONE COMPONENT MONITOR image output DISABLE pin
EXP20 Z2 MONIDIS ZONE2 COMPONENT MONITOR image output DISABLE pin
EXP21 Z1 IN RL MAIN ZONE COMPONENT IN switching control
EXP22 Z2 IN RL ZONE2 COMPONENT IN switching control
EXP23 Z1 MONI RL MAIN ZONE COMPONENT MONITOR switching pin
EXP24 Z2 MONI RL ZONE2 COMPONENT MONITOR switching pin
1U-3822
IC104
EXP25 LINEA D pin LINE control pin(JP only)
EXP26 LINEB D pin LINE control pin(JP only)
EXP27 INH_LINE D pin LINE control pin(JP only)
EXP28 ASPECT_H ASPECT ratio level control(JP only)
EXP29 ASPECT_L ASPECT ratio level control(JP only)
EXP30 NC NC
EXP31 NC NC
EXP32 NC NC
Part Name Pin Name Symbol Function
