AVR-2310CI/2310/890, AVC-2310
PCB 2CH ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q401SBL 00D9630235301 TR 2SD2560Y
J5032560Y0170S
Q401SBR 00D9630235301 TR 2SD2560Y J5032560Y0170S
Q402SBL 00D9630235204 TR 2SB1647Y J5011647Y0170S
Q402SBR 00D9630235204 TR 2SB1647Y J5011647Y0170S
Q403SBL 963219003340S TR KTC3964 J502396400010S
Q403SBR 963219003340S TR 2SC KTC3964 J502396400010S
Q404SBL 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q404SBR 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q406SBL 00D9600196302 TR KTA1268BL J5001268B0050S
Q406SBR 00D9600196302 TR KTA1268BL J5001268B0050S
Q407SBL 00D9600196302 TR KTA1268BL J5001268B0050S
Q407SBR 00D9600196302 TR KTA1268BL J5001268B0050S
Q408SBL 00D9600196700 TR KTC3200BL J5023200B0050S
Q408SBR 00D9600196700 TR KTC3200BL J5023200B0050S
Q409SBL 00D2710318909 TR 2SA 2N5401S J520254010010S
Q409SBR 00D2710318909 TR 2SA 2N5401S J520254010010S
Q411 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q412,413 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q414 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
D401SBL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D401SBR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D402 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D402SBL 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D402SBR 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D403,404 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D405,406 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D406SBL 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D406SBR 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D407-411 00D9630020309 D,SWITCHING 1SS133T K000013300520S
D2270,2271 00D9600197107 D,RECTIFIER BRIDGE KBPC604 K047604000020S
ZD401SBL 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD401SBR 00D9630367008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD402SBL 00D9630382209 D,ZENER 0.2W 3.0V UDZ K06603R04P400S
ZD402SBR 00D9630382209 D,ZENER 0.2W 3.0V UDZ K06603R04P400S
RESISTORS GROUP
R410SBL nsp R,METAL FILM 1K-J,1W
C060010265050S
R410SBR nsp R,METAL FILM 1K-J,1W C060010265050S
R411SBL nsp R,METAL FILM 270-J,1W C060027165060S
R411SBR nsp R,METAL FILM 270-J,1W C060027165060S
R419SBL nsp R,METAL FILM 22-J,1W C060022065060S
R419SBR nsp R,METAL FILM 22-J,1W C060022065060S
R420SBL nsp R,METAL FILM 22-J,1W C060022065060S
R420SBR nsp R,METAL FILM 22-J,1W C060022065060S
R421SBL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R421SBR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R422SBL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R422SBR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R423SBL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R423SBR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R424SBL 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R424SBR 00D9630345903 R,FIXED 2WJ-0.47 N113136647820S
R429SBL 00D9639006256 R,FIXED 1WJ-10 N113135610020S
