Denon AVR-890 Service Manual

111111
AVR-2310CI/2310/890, AVC-2310
PCB INPUT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC700 963239000650S IC R2A15218FP
J084152180010S
IC706,707 963239001880S IC AZ4580M J121458000020S
IC715 00D9630024004 IC NJM2068M J121206800020S
IC806 963239001880S IC AZ4580M J121458000020S
Q700-707 00D9630044301 TR KTC2875B(MB) J5222875B0010S
ZD700 00D9600222603 D,ZENER MTZJ7.5A K06007R544530S
ZD702 00D9600222603 D,ZENER MTZJ7.5A K06007R544530S
RESISTORS GROUP
R844,845 963125004330S R,METAL FILM 82-J,1W
C060082065050S
R857,858 00D9639005639 R,METAL FILM 100-J,1W C060010165060S
CAPACITORS GROUP
C700-709 nsp C,CERAMIC 330PF-J/50V
D010331167160S
C710-719 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C750-753 nsp C,CERAMIC 20PF-J/50V D010200167160S
C754-757 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C758-761 nsp C,CERAMIC X7R0.047UF-K/16V D011473773160S
C766-769 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C770-777 nsp C,CERAMIC 330PF-J/50V D010331167160S
C778-785 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C810-817 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C818-825 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C837-844 00D9639005820 C,ELECT 22UF-M/16V D040220083070S
C848-853 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C854,855 00D9639006214 C,ELECT 3.3UF-M/50V D0403R3087050S
C856,857 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C858,859 nsp C,CERAMIC 100PF-J/50V D010101167160S
C860-867 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C868,869 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C884 nsp C,CERAMIC 330PF-J/50V E1C D010331167160S
C885 00D9630234205 C,ELECT 10UF-M/50V E1C D040100087070S
C888 nsp C,CERAMIC 220PF-J/50V D010221167160S
C888L nsp C,CERAMIC X7R0.047UF-K/16V D011473773160S
C888R nsp C,CERAMIC X7R0.047UF-K/16V D011473773160S
C889 00D9630223009 R,THICK 0-J,1/16W C20000006M160S
C889L 00D9609010010 C,ELECT 4.7UF-M/50V D0404R7087250S
C889R 00D9609010010 C,ELECT 4.7UF-M/50V D0404R7087250S
C890 nsp C,CERAMIC 220PF-J/50V D010221167160S
C890L nsp C,FILM POLYESTER ST-0.0068UF-J/100V D02068206C060S
C890R nsp C,FILM POLYESTER ST-0.0068UF-J/100V D02068206C060S
C891 00D9630223009 R,THICK 0-J,1/16W C20000006M160S
C891L nsp C,FILM POLYESTER M1-0.024UF-J/50V D020243167050S
C891R nsp C,FILM POLYESTER M1-0.024UF-J/50V D020243167050S
C892 00D9630223009 R,THICK 0-J,1/16W C20000006M160S
C892L nsp C,CERAMIC 100PF-J/50V D010101167160S
C892R nsp C,CERAMIC 100PF-J/50V D010101167160S
C893 nsp C,CERAMIC 220PF-J/50V D010221167160S
C893L 00D9639006557 C,ELECT 220UF-M/6.3V D040221081060S
C893R 00D9639006557 C,ELECT 220UF-M/6.3V D040221081060S
