AVR-2310CI/2310/890, AVC-2310
PCB VIDEO ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC2002-2004 00D2623445901 IC TC4051BFT
J040405101010S
IC2005,2006 232810005504S IC BD7628F-E2 J127762800010S
IC2014,2015 00D2623446900 IC TC4052BFT J040405201010S
IC2016 00D2623756904 IC LA73053 J127730530010S
IC2019 00D9630218807 IC BU4094BCF-E2 J040140940030S
IC2021,2022 00D9630327604 IC NJM2581M J127258100010S
IC2023 00D2623551002 IC NJW1321FP1 J171132100010S
IC2024 00D2623755905 IC LA73062V-TLM-E J127730620010S
IC2025,2026 00D2622813903 SN74AHCT08PW-EL2 +C J040740800190S
Q2001-2004 00D9630120801 TR KRC102S J522010200210S
Q2005,2006 00D9630148508 TRKTA1504S J520015040150S
Q2010 00D9630120801 TR KRC102S J522010200210S
Q2011 00D9630121606 TR KRC107S J522107S00210S
Q2012 00D9630148508 TRKTA1504S J520015040150S
Q2013-2015 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q2016-2018 00D9630121402 TR 2SA KRA104S R1 J520010400210S
Q2019-2021 00D9600285006 TR KRC104S J522104S00210S
D2001-2004 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D2014 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D2018 00D9630355401 D,SWITCHING KDS4148U K005041480030S
CAPACITORS GROUP
C658 nsp C,CERAMIC 0.1UF-K/50V
D011104577160S
C2001 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2002 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C2003-2006 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C2008 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2009,2010 00D9630294203 C,ELECT 33UF-M/16V D040330083050S
C2011,2012 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2013,2014 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C2015,2016 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C2017-2020 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C2022 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2023-2026 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C2029 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C2057 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2059 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C2061,2062 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2063 00D9630294203 C,ELECT 33UF-M/16V D040330083050S
C2064 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2065,2066 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C2067 00D9630294203 C,ELECT 33UF-M/16V D040330083050S
C2068 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2069,2070 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C2073 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2074 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2075 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2076 00D9630276409 C,ELECT 100UF-M/16V D040101083090S
C2084 00D9630294203 C,ELECT 33UF-M/16V D040330083050S
C2086 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C2102 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
