Denon AVR-890 Service Manual

116116
AVR-2310CI/2310/890, AVC-2310
PCB CPU ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC38 00D2622813903 SN74AHCT08PW-EL2 +C
J040740800190S
IC801 00D9630326906 IC LC72722PM-TLM-E 2310E2 J124727220010S
IC802 963243005240D IC M30879FLBFP J020308790010S
IC803 00D9630367307 IC SN74AHCU04PWR J040740400290S
IC804 00D9630244907 IC SN74LV14APWR J040741400180S
IC805 00D2622813903 IC SN74AHCT08PW-EL2 +C J040740800190S
IC806-808 00D2622517908 IC SN74LVO8APW-EL2 J040740800200S
Q804 00D9630327808 TR KTA1281Y J5001281Y0010S
Q805 00D9630120801 TR KRC102S J522010200210S
Q806 00D9630120704 TR KRA102S 2310E2,E3 J520010200210S
Q807,808 00D9630121509 TR KTC3875S J522038750210S
Q809-812 00D9630044301 TR KTC2875B(MB) 2310E2,E3 J5222875B0010S
D800-802 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D803 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D804,805 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D806,807 00D9630245100 D,SWITCHING KDS226ST1(C3) K005022600020S
D808 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D809-811 963209003510S D,ESD CDS3C05HDMI1 K067030500010S
D812,813 00D9630355401 D,SWITCHING KDS4148U K005041480030S
ZD800 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
RESISTORS GROUP
R887 00D9639005639 R,METAL FILM 100-J,1W
C060010165060S
CAPACITORS GROUP
C658,659 nsp C,CERAMIC 0.1UF-K/50V
D011104577160S
C804 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C805-810 nsp C,CERAMIC 100PF-J/50V D010101167160S
C813 nsp C,CERAMIC 560PF-J/50V 2310E2 D010561167160S
C814 00D9630234205 C,ELECT 10UF-M/50V 2310E2 D040100087070S
C815 00D9639005862 C,ELECT 47UF-M/16V 2310E2 D040470083080S
C816,817 nsp C,CERAMIC 27PF-J/50V 2310E2 D010270167160S
C818 nsp C,CERAMIC 330PF-J/50V 2310E2 D010331167160S
C819 nsp C,CERAMIC 0.01UF-K/50V 2310E2 D011103777160S
C820 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C821,822 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C823 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C824 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C825 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C826 nsp C,CERAMIC 0.1UF-K/50V E2, E3, EA D011104577160S
C827 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C830 00D9609010010 C,ELECT 4.7UF-M/50V D0404R7087250S
C831 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C832 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C837 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C838 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C840 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C841 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C843,844 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C845 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C846 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
