Denon AVR-890 Service Manual

118118
AVR-2310CI/2310/890, AVC-2310
PCB SIRIUS ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC901 00D9630024004 IC NJM2068M E3, EA
J121206800020S
IC902 00D2623174900 IC SN74HAHCT08 J040740800180S
IC903 00D2623571901 IC HIN202EIBN 2310E3/E2 J040202000020S
IC904 00MHC007805K0 IC TC74VHCT125AFT 2310E3/E2 J040741250080S
Q906 00D9630148508 TRKTA1504S J520015040150S
Q908 00D9630121606 TR KRC107S J522107S00210S
Q909 00D9630120801 TR KRC102S 2310E3/E2 J522010200210S
D901 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D910,911 963209003510S D,ESD CDS3C05HDMI1 E3, EA K067030500010S
CAPACITORS GROUP
C901,902 nsp C,CERAMIC 0.1UF-K/50V E3, EA
D011104577160S
C903 963134002720S C,ELECT 10UF-M/50V(Pb Free) E3, EA D040100087080S
C904 nsp C,CERAMIC 330PF-J/50V E3, EA D010331167160S
C905 963134002720S C,ELECT 10UF-M/50V (Pb Free) E3, EA D040100087080S
C906-908 nsp C,CERAMIC 330PF-J/50V E3, EA D010331167160S
C909,910 963134002720S C,ELECT 10UF-M/50V (Pb Free) E3, EA D040100087080S
C911 00D9609010751 C,ELECT 4.7UF-M/50V D0404R7087090S
C912 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C913 nsp C,CERAMIC 100PF-J/50V E3, EA D010101167160S
C914-917 00D9630130503 C,ELECT 0.1UF-M/50V 2310E3/E2 D040R10087060S
C918 nsp C,CERAMIC 100PF-J/50V E3, EA D010101167160S
C919,920 963134002720S C,ELECT 10UF-M/50V (Pb Free) E3, EA D040100087080S
C927 nsp C,CERAMIC 0.1UF-K/50V E3, EA D011104577160S
C928-930 nsp C,CERAMIC 100PF-J/50V 2310E3/E2 D010101167160S
C932 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C933 nsp C,CERAMIC 0.1UF-K/50V 2310E3/E2 D011104577160S
C934 963134005100S C,ELECT 100UF-M/10V (Pb Free) SY 2310E3/E2 D040101082130S
C937 nsp C,CERAMIC 0.1UF-K/50V E3, EA D011104577160S
C938 nsp C,CERAMIC 1000PF-K/50V E3, EA D011102777160S
C939 nsp C,CERAMIC 0.1UF-K/50V 2310E3/E2 D011104577160S
OTHERS PARTS GROUP
BD901,902 963115003230S COIL,BEAD CBW160808U121T E3, EA
D340160811210S
BD903-905 963115003230S COIL,BEAD CBW160808U121T 2310E3/E2 D340160811210S
BD906 963115003230S COIL,BEAD CBW160808U121T D340160811210S
BKT900 nsp BRACKET 0.8t/SCREW 4010210196100S
CN901 nsp CN.HOUSING 9P L120912190010S
JACK902 nsp CN.WAFER 9P 2310E3/E2 L103090090030S
JACK1008 00D9630333601 MINI DIN CONNECTOR 8P YKF51-5397N E3, EA G403515397000S
