Symptom Cause / Solution Page
Dolby PLg mode or DTS
Neo:6 mode cannot be
selected.
0
It cannot be selected when “Speaker Config.” - “Center” or “Surround” is set for “None”. 168
0
Dolby PLg or DTS Neo:6 cannot be selected when using headphones.
－
Audyssey MultEQ
®
,
Audyssey Dynamic EQ
®
and Audyssey Dynamic
Volume
®
cannot be
selected.
0
These cannot be selected when you have not performed Audyssey
®
Setup.
157
0
Switch to a sound mode other than “Direct”. 113
0
These cannot be selected when using the headphones. －
“Restorer” cannot be
selected.
0
Check that an analog signal or PCM signal (Sample Rate = 44.1/48 kHz) is input. For playback of
multichannel signals such as Dolby Digital or DTS surround, “Restorer” cannot be used.
142
0
Switch to a sound mode other than “Direct”. 113
No sound is output when
using ZONE2.
0
Digital signal audio input from the HDMI connector or digital audio connectors (OPTICAL/COAXIAL)
cannot be played back. Use analog connections.
－
0
When listening to the audio of a Bluetooth device in ZONE2, remove any obstructions between the
Bluetooth device and this unit and use it within a range of about 32.8 ft/10 m.
－
Contents Connections Playback Settings Tips Appendix
197
Front panel Display Rear panel Remote Index

Denon AVR-S700W Specifications

General

Channels	7.2
Power Output per Channel	75 W (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Signal-To-Noise Ratio	98 dB
Input Impedance	47 kOhms
Input Sensitivity	200 mV
HDMI Inputs	6
HDMI Outputs	1
Composite Inputs	2
Component Inputs	2
Analog Inputs	4
Composite Output	1
Component Output	1
Wi-Fi	Yes
Bluetooth	Yes
AirPlay	Yes
DLNA	Yes
HDMI Pass-Through	Yes
HDMI Switching	Yes
3D Technology	Yes
Digital Inputs	2 Optical
Supported Audio Formats	DTS-HD Master Audio, Dolby TrueHD
Supported Video Formats	4K, 3D
Additional Features	Audyssey MultEQ
Tuner Presets	56
Dimensions	17.1 x 13.3 x 6.6 inches
