Denon is a trademark or registered trademark of D&M Holdings, Inc.
* All specs can be subject to change
* Available only in Black
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey
07430 USA
TEL: 201-762-6500
usa.denon.com
|V01|
Technical information
Number of power amps 7 Preamplifier section
Input sensitivity/impedance 200 mV / 47 kohms
Power output 165 watts per channel Frequency response 10 Hz - 100 kHz — +1, –3 dB
(6 ohms, 1kHz, 1ch driven) (DIRECT mode)
S/N Ratio 98 dB (IHF-A weighted, DIRECT mode)
75 watts per channel
(8 ohms, 20Hz - 20 kHz, THD 0.08%, 2ch driven) FM section
Tuning frequency range 87.5 - 107.9 MHz
Output connectors 4 - 16 ohms
AM section
Tuning frequency range 520 - 1710 kHz
General
Power supply AC 120 V, 60 Hz
Power consumption 400 W (Standby 0.1 W, CEC standby 0.5 W)
Dimensions (W x H x D) 17.1” x 5.9”x 13.3”
Weight 18.9 lbs
Ports
IN HDMI (front 1) x 5
Composite (video) x 2
Analogue Audio x 2
Digital Optical x 2
OUT HDMI Monitor x 1
Composite Monitor x 1
Audio Preout (SW) 0.2 ch
Phones x 1
OTHER Ethernet x 1
USB Port x 1
Microphone Port x 1
FM Tuner Antenna x 1
AM Tuner Antenna x 1
4K Ultra HD 60 Hz Pass-through; 4:4:4 Pure Color
Sub-sampling Pass-through
With 6 HDMI inputs, the AVR-S700W lets you connect multiple HDMI
source devices. The Blu-ray and Game inputs support 4K Ultra HD
60 Hz and 4:4:4 Pure Color video pass-through, a feature of the lat-
est HDMI specification. The AVR-S700W’s video section is also fully
compatible with 3D content.
Built-in Bluetooth, Built-in Wi-Fi and AirPlay, DLNA
Many portable devices are equipped with Bluetooth wireless con-
nectivity, and the AVR-S700W’s built-in Bluetooth wireless technolo-
gy lets you stream your favorite audio tracks from up to 8 Bluetooth-
enabled devices, such as smartphones, portable audio players and
tablets.
With the built-in Wi-Fi wireless technology, the AVR-S700W connects
to the internet through your home network, opening up a world of
music from internet radio stations, as well as via streaming sub-
scription services, including Pandora, Spotify Connect and SiriusXM.
With AirPlay, you can enjoy listening to your favorite tracks wirelessly
from your portable iOS device, including iPhone, iPod touch, and
iPad. DLNA 1.5 certification lets you connect to your PC or Mac via
your home network wirelessly for additional streaming capabilities.
Our Denon Remote App lets you easily control the AVR-S700W with
your favorite portable device, and is available for Apple and Android
devices as well as the Kindle Fire.
Easy To Setup, Easy To Use
Denon’s exclusive Setup Assistant, along with our Quick Start guide,
will have your system properly connected and configured quickly
and easily, so you can start enjoying superb home theater surround
sound with a minimum of fuss and bother. The Setup Assistant fea-
tures clear on-screen graphics and text that quickly and easily guide
you through the setup process, optimizing critical system settings for
the best possible sound quality.
Convenient USB Port
Connect your Apple iPod, iPod touch or iPad to the AVR-S700W via
the convenient front panel USB port and listen to your favorite music
tracks while charging your device at the same time.
Powerful 7 Channel Discrete Amplifier with Eco Mode
Featuring high current discrete power output devices, the AVR-S700W
delivers high power and is rated at a maximum of 165 watts per
channel. There’s also an Auto Eco mode that adjusts the maximum
power available according to the volume level, as well as an on-
screen Eco meter that lets you see the power consumption reduction
in real time.
For compatibility with the widest range of loudspeaker models, the
AVR-S700W is also equipped with low impedance drive capability, to
provide operational stability with speakers rated at 4 ohms.
Audyssey Bronze Built-in
Denon was the first A/V manufacturer to embrace Audyssey’s
advanced DSP audio processing, and the AVR-S700W features the
Audyssey Bronze suite of powerful DSP features, including MultEQ
room acoustic measurement and DSP correction. Via the supplied
measuring microphone, Audyssey MultEQ measures all the speak-
ers in your home theater during setup, including the subwoofer, and
then generates multiple high precision DSP room acoustic correction
filters, which together provide smoothest and most natural tonal bal-
ance, regardless of the brand or model of the various speakers.
Audyssey Dynamic Volume features advanced psycho-acoustic
processing to deliver clear dialog and wide range sound at reduced
volume levels so that you can enjoy theater-level clarity at whatever
listening level you choose. Audyssey Dynamic EQ also features
advanced DSP processing to deliver full range wide-band response,
even at reduced volume levels.
Multi-room Listening
You can configure the AVR-S700W for a 7 channel home theater
surround system, or you can choose to have a 5 channel surround
system in the main room, with 2 of the amplifier channels dedicated
to drive separate stereo speakers in another room. Enjoy a surround
sound movie in one room, while others can enjoy stereo sound from
a different source in a second room, at the same time.
Dual Subwoofer Outputs
The AVR-S700W features dual subwoofer outputs, which lets you
connect two smaller subwoofers instead of a single, larger sub,
and enjoy the benefits of response averaging by having two subs
in different locations in the room. With dual subwoofers, deep bass
is smoother and more detailed, minimizing the peaks and dips that
often result with a single subwoofer setup.
KEY FEATURES
• 7.2ch platform
• 165W (6ohm, 1kHz, 1ch driven)
• 4K/60Hz full-rate pass-through (via Blu-ray and Game Inputs)
• Built-in Wifi and Bluetooth
• Networking: AirPlay, Android push playback, Internet Radio,
Pandora, Spotify Connect, Sirius XM, DLNA 1.5
• Audyssey MultEQ setup with measuring microphone included
in the box / Dynamic EQ & Volume
• Dolby PLIIz
STATE-OF-THE-ART DENON SOLUTIONS FOR MAXIMISING
CONTENT QUALITY AND CONNECTIVITY
• HDMI : Front 1in, Rear 5in/1out
• Digital audio inputs: 2 Opt /1 Coax
• Audio: 2in, Video: Composite 2in/1out
• Front panel USB input with iPod digital direct
• AM/FM Radio
• 2-zone/2-source via variable amplified zone
EASE-OF-USE AND OTHER FEATURES
• ECO mode
• Setup assistant with icon-based GUI
• Horizontal layout speaker terminals with color labelling
• Speaker cable labels supplied
• Larger Character Display
• 4 Quick Select buttons and RC buttons - can be used to store
favorite sources, internet radio stations and preferred settings
• Sleep Timer, set up to 120 minutes in 10-minute increments
• Standby HDMI pass-through
• Simple Remote handset
• Android, Kindle Fire and iOS remote apps available
