Denon AVR-S770H User Manual

oQ0i
trqw e y
u
A
Power operation button (X)
Used to turn the power of the MAIN ZONE (room where this unit is
located) on/off (standby). (v p. 63)
B
Power indicator
This is lit as follows according to the power status:
0
Green: Power on
0
Off: Normal standby
0
Red:
0
When “HDMI Pass Through” is set to “On” (v p. 165)
0
When “HDMI Control” is set to “On” (v p. 167)
0
When “Network Control” is set to “Always On” (v p. 200)
C
SOURCE SELECT knob
This selects the input source. (v p. 63)
D
Remote control sensor
This receives signals from the remote control unit. (v p. 9)
E
Display
This displays various pieces of information. (v p. 19)
F
MASTER VOLUME knob
This adjusts the volume level. (v p. 64)
G
ZONE2 ON/OFF button
This turns the power of ZONE2 (another room) on/off. (v p. 142)
H
ZONE2 SOURCE button
This selects the input source for ZONE2. (v p. 142)
I
Tuner preset channel buttons
(TUNER PRESET CH +, –)
These select preset broadcast stations. (v p. 84)
J
Tuning up / Tuning down buttons (TUNE +, –)
Select either FM broadcast or AM broadcast. (v p. 78)
Contents Connections Playback Settings Tips Appendix
17
Front panel Display Rear panel Remote Index

Denon AVR-S770H Specifications

General

Channels	7.2
HDMI Inputs	6
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
Input Sensitivity/Impedance	200mV/47k ohms
Signal-to-Noise Ratio	98 dB (IHF-A weighted, Direct mode)
Ethernet Port	Yes
HDR Support	HDR10+, Dolby Vision, HLG
Frequency Response	10Hz-100kHz
USB Port	Yes
HDMI Outputs	1
