Denon AVR-S770H User Manual

Q1 Q2 Q3 Q4
Q
9
Q
8
Q
5
Q
6
Q
7
K
Reception band select button (BAND)
This switches the reception band. (v p. 78)
L
Tune mode select button (MODE)
This switches the tuning mode. (v p. 83)
M
DIMMER button
Each press of this switches the brightness of the display. (v p. 212)
N
STATUS button
Each press of this switches the status information that is shown on the
display.
O
Headphones jack (PHONES)
This is used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers or from the SUBWOOFER
connectors.
NOTE
0
To prevent hearing loss, do not raise the volume level excessively when using
headphones.
P
SETUP MIC jack
This is used to connect the supplied Sound calibration microphone.
(v p. 181)
Q
QUICK SELECT buttons
With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings. (v p. 131)
R
SOUND MODE buttons
These select the sound mode. (v p. 116)
S
USB port (T)
This is used to connect USB storages (such as USB memory devices).
(v p. 56)
Contents Connections Playback Settings Tips Appendix
18
Front panel Display Rear panel Remote Index

Denon AVR-S770H Specifications

General

Channels	7.2
HDMI Inputs	6
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
Input Sensitivity/Impedance	200mV/47k ohms
Signal-to-Noise Ratio	98 dB (IHF-A weighted, Direct mode)
Ethernet Port	Yes
HDR Support	HDR10+, Dolby Vision, HLG
Frequency Response	10Hz-100kHz
USB Port	Yes
HDMI Outputs	1
