Denon AVR-X1200W Service Manual

Pin Pin Name Symbol I/O Pu/Pd
Lv
Cnv
STBY STOP
CEC
STBY
Function
107 PE2/D10 VOL CLK O L L L
Input selecter w/ E.volume(NJU72340A) control
pin
108 PE1/D9 VOL DATA O L L L
Input selecter w/ E.volume(NJU72340A) control
pin
109 PE0/D8 PLD WRITE O L L L
Audio PLD (5M80ZT100C5N) control pin
110 PD7/D7 JTAG TDO I L L L
Audio PLD (5M80ZT100C5N) control pin
111 PD6/D6
JTAG TMS/
APLD CS
O/O L L L
Audio PLD (5M80ZT100C5N) control pin
112 PD5/D5
JTAG TDI/APLD
DATA/DAC
DATA
O/O L L L
Audio PLD (5M80ZT100C5N) control pin
113 PD4/D4
JTAG TCK/
APLD CLK/DAC
CLK
O/O L L L
Audio PLD (5M80ZT100C5N) control pin
114 P64/CS4#-B VEXP STB O L L L
EXPANDER (MC14094) control pin
115 P63/CS3#-A/CS7#-A THERMAL A I SW3VPu I L I
PROTECTION detect signal input pin
116 P62/CS2#-A/CS6#-A E SPI CS O N3VPu L L L
ETHERNET(CY920) control pin
117
P61/CS1#/CS2#-B/
CS5#-A/CS6#-B/
CS7#-B
DAC MS O L L L
DAC (PCM1690) control pin
118
P60/CS0#/CS4#-A/
CS5#-B
DAC RST O L L L
DAC (PCM1690) control pin
119 PD3/D3 VEXP CLK O L L L
EXPANDER (MC14094) control pin
120 PD2/D2 VEXP DATA O L L
L
EXPANDER (MC14094) control pin
121 PD1/D1 FL CLK O L L L
Fluorescent display control pin
122 PD0/D0 FL DATA O L L L
Fluorescent display control pin
123 P97/AN15 DA POWER O L L L
DIGITAL AUDIO power supply control pin
124 P96/AN14 CEC POWER O L L
※ CEC STANDBY power supply control
125 P95/AN13 DV POWER1 O L L
※ DIGITAL VIDEO power supply control pin
126 P94/AN12 THERMAL B I SW3VPu I L I
PROTECTION detect signal input pin
127 P93/AN11 MAIN POWER O L L L
Power supply control pin
128 P92/AN10 CPU POWER O L L L
CPU POWER supply control pin
129 P91/AN9 AMPSIGDET I I L I
AMP sig. detect signal input pin
130 VSS VSS - - - -
Ground pin.
131 P90/AN8 MODE I I I I
Region setting pin
132 VCC VCC - - - -
Power supply pin.
133 P47/IRQ15-B/AN7 DC DET/ASO I I I I
PROTECTION detect signal input pin
134 P46/IRQ14-B/AN6
H/P DET / MIC
DET
I I I I
Headphone insert detect pin
135 P45/IRQ13-B/AN5 KEY3 I SW3VPu I I I
Key control signalinput pin
136 P44/IRQ12-B/AN4 KEY2 I SW3VPu I I I
Key control signalinput pin
137 P43/IRQ11-B/AN3 KEY1 I SW3VPu I I I
Key control signalinput pin
138 P42/IRQ10-B/AN2 E SPI REQ I Pd I L I
ETHERNET(CY920) control pin
139 P41/IRQ9-B/AN1 CURRENT DET I I L I
Current level monitor pin
140 AVSS AVSS - - - -
Ground pin.
141 P40/IRQ8-B/AN0 CEC_IN I SW3VPu I I I
CEC-D control pin
142 VREF VREF - - - -
Reference power supply pin
143 AVCC AVCC - - - -
Analog power supply pin
144
P05/IRQ13-A/TMO3/
RxD4/TCK
TCK/RXD
MITSUBISHI/
NC(NORMRAL)
I/I/I M3VPu -/-/I -/-/I I
E20 Emulator control pin
132
