Denon AVR-X1200W Service Manual

Jump to the target of a schematic
diagram connector
Click the Ref. No. of the target connector in the red
box around a schematic diagram connector.
•The screen jumps to the target connector.
•Pagemagnicationstaysthesameasbeforethe
jump.
CP401
CP106
v
ABOUT THIS MANUAL
Readthefollowinginformationbeforeusingtheservicemanual.
What you can do with this manual
Search for a Ref. No. (phrase)
(Ctrl+Shift+F)
YoucanusethesearchfunctioninAcrobatReaderto
searchforaRef.No.inschematicdiagrams,printed
wiringcircuitdiagrams,blockdiagrams,andparts
lists.
1.PressCtrl+Shift+Fonthekeyboard.
• TheSearchwindowappears.
2.EntertheRef.No.youwanttosearchforinthe
Searchwindow,andthenclicktheSearchbutton.
•Alistofsearchresultsappears.
3.Clickanitemonthelist.
•Thescreenjumpstothepageforthatitem,andthe
searchphraseisdisplayed.
Ctrl
Shift
F
3

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
