Denon AVR-X1200W Service Manual

MAIN
REF No. Part No. Part Name Remarks Q'ty New Ver
R5429 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5430,5431 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5432 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5433 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R5513 nsp RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5514 nsp RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5515,5516 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5517,5518 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5519-5522 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R5523 nsp RES, CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5524 nsp RES, CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5525 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5526 252310006506S PTC THEMISTORS, CHIP(115'C)
CRTPRF18BB471QB5RB
1
R5527 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5529 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5530,5531 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5532 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5533 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R5613 nsp RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5614 nsp RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5615,5616 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5617,5618 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5619-5622 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R5623 nsp RES, CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5624 nsp RES, CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5625 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5626 252310006506S PTC THEMISTORS, CHIP(115'C)
CRTPRF18BB471QB5RB
1
R5627 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5629 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5630,5631 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5632 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5633 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R5713 nsp RES, CARBON(1/5W,2.7Kohm,J) CRD20TJ272T 1
R5714 nsp RES, CARBON(1/5W,560ohm,J) CRD20TJ561T 1
R5715,5716 nsp RES, M-OXIDE FILM(1W/5.6Kohm) CRG1SANJ562RT 2
R5717,5718 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 2
R5719-5722 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 4
R5723 nsp RES, CARBON(1/5W,820Kohm,J) CRD20TJ824T 1
R5724 nsp RES, CARBON(1/5W,180Kohm,J) CRD20TJ184T 1
R5725 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
! R5726 252310006506S PTC THEMISTORS, CHIP(115'C)
CRTPRF18BB471QB5RB
1
R5727 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R5729 nsp RES, CARBON(1/5W,15Kohm,J) CRD20TJ153T 1
R5730,5731 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 2
R5732 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R5733 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R5801,5802 nsp RES, M-OXIDE FILM(2W/470ohm) CRG2SANJ471RT 2
R5803 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5804 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1
R5805 nsp RES, CARBON(1/5W,100Kohm,J) CRD20TJ104T 1
R5806 nsp RES, CARBON(1/5W,12Kohm,J) CRD20TJ123T 1
R5807,5808 nsp RES, CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 2
R5809 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1
R5810 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5811 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R5812-5818 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 7
R5819 nsp RES, M-OXIDE FILM(1W/100ohm) CRG1SANJ101RT 1
R5820 nsp RES, M-OXIDE FILM(1W/33ohm) CRG1SANJ330RT 1
R5821 nsp RES, M-OXIDE FILM(1W/2.2Kohm) CRG1SANJ222RT 1
R5823,5824 nsp RES, M-OXIDE FILM(1W/2.2Kohm) CRG1SANJ222RT 2
R5827 943129501040S RES , CEMENT (5W, 0.01 OHM, 5% SMALL SIZE) CRF5EJR01HS 1 *
R5830 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R5831 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5832 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5833 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R5834 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R5835 nsp RES, CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
R5836 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R5837 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5838 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R5839,5840 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R5841 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1
R5842 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1
R5843-5845 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 3
R5846 nsp RES, CARBON(1/5W,2.2Kohm,J) CRD20TJ222T 1
CAPACIITORS GROUP
C5107 nsp CAP, ELECT(50V/47uF) E3, E1C, JP, S710 CCEA1HH470T 1
C5107 nsp CAP, ELECT(16V/220uF) E2 CCEA1CH221T 1
C5108 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5109 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5110 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5111 nsp CAP, MYLAR(50V/0.018uF/J) HCQI1H183JZT 1
C5113 nsp CAP, MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5120 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5207 nsp CAP, ELECT(50V/47uF) E3, E1C, JP, S710 CCEA1HH470T 1
C5207 nsp CAP, ELECT(16V/220uF) E2 CCEA1CH221T 1
C5208 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5209 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5211 nsp CAP, MYLAR(50V/0.018uF/J) HCQI1H183JZT 1
C5213 nsp CAP, MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5307 nsp CAP, ELECT(50V/47uF) E3, E1C, JP, S710 CCEA1HH470T 1
C5307 nsp CAP, ELECT(16V/220uF) E2 CCEA1CH221T 1
C5308 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5309 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5310 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5311 nsp CAP, MYLAR(50V/0.018uF/J) HCQI1H183JZT 1
C5313 nsp CAP, MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5407 nsp CAP, ELECT(50V/47uF) E3, E1C, JP, S710 CCEA1HH470T 1
C5407 nsp CAP, ELECT(16V/220uF) E2 CCEA1CH221T 1
C5408 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5409 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5410 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5411 nsp CAP, MYLAR(50V/0.018uF/J) HCQI1H183JZT 1
C5413 nsp CAP, MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5507 nsp CAP, ELECT(50V/47uF) E3, E1C, JP, S710 CCEA1HH470T 1
C5507 nsp CAP, ELECT(16V/220uF) E2 CCEA1CH221T 1
C5508 nsp CAP , ELECT(63V/100uF) CCEA1JH101T 1
C5509 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C5510 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1
C5511 nsp CAP, MYLAR(50V/0.018uF/J) HCQI1H183JZT 1
C5513 nsp CAP, MYLAR(50V/1500pF/J) HCQI1H152JZT 1
C5607 nsp CAP, ELECT(50V/47uF) E3, E1C, JP, S710 CCEA1HH470T 1
C5607 nsp CAP, ELECT(16V/220uF) E2 CCEA1CH221T 1
7

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
