1.11. Device display during the î™°rmware update
Display the device being updated and the update progress.
Target device USB Update Display Error code when an error occurs
Main CPU
L1
M a i n : * * % * * * m i n
10 - 16
36 - 3D
3F
Audio PLD
L1
A P L D : * * % * * * m i n
50 - 52
54 - 57
5A - 64
DSP
L1
D S P : * * % * * * m i n
50 - 52
54 - 57
5A - 64
GUI Serial Flash
L1
G U I : * * % * * * m i n
50 - 52
54 - 57
5A
62 - 64
80 - 86
CY920 second
Boot Loader
L1
E S B L : * * % * * * m i n
A2 - A4
A6 - A7
AE - AF
B1 - B5
CY920
L1
E I M G : * * % * * * m i n
A2 - A4
A6 - A7
AE - AF
B1 - B5
CY920 Image (Emergency
Mode)
L1
U p d a t e r e t r y
–
---Checking the Firmware Version After the Update---
After updating the î™°rmware, check the version. See "1. Version Display Mode" (page 21).
