Denon AVR-X1200W Service Manual

DSP
DAC
SPK OUT
NJU72340A
SURROUND BACK
SURROUND BACK CHANNEL
PLD
PCM1690
CS49844A
GAIN
ADJ.
5M80ZT
0dBFS=+/-4.0Vpp=2.83Vrms
DIFF.OUT
NJU72340 MAX.OUTPUT 3.8Vrms
NJM8080 MAX.OUTPUT 7.78Vrms
-3.01dB
POWERAMP GAIN
+29dB
150mVrms
PRE OUT
+3.5dB
(2)(1)
=+1.0dB
=-2.5dB
-2.5dB
-2.5dB
(2):OFFSET of the AD input ATT
(1):Basic OFFSET of VOL=0dB ( PREAMPGAIN:+15.5dB at VOLMAX)
- ANALOG IN
GAIN setting of MASTER VOL 00dB
- DIGITAL IN
SPK OUT
4.27Vrms/8ohm
+1.0dB
-2.5dB
-3.01dB
FULL SCALE LEVEL=2.0Vrms
ANA INPUT:200mVrms L+R 1kHz
(MODE:MULTI CH
STEREO)
DD INPUT:-20dBFS SURR.B 1kHz
-40dBFS
-30dBFS
-20dBFS
0dBFS
-10dBFS
PCM1690
DAC
+30dB
-50dB
+20dB
+10dB
-30dB
-40dB
-20dB
-10dB
(200mVrms)0dB
-50dB
+20dB
+10dB
-30dB
-40dB
-20dB
-10dB
(200mV)
2CH IN 0dB
DSP OUTOPUT:-23.5dBFS
DSP OUTOPUT:-20dBFS
91

Denon AVR-X1200W Specifications

General

HDMI in	6
AC (power) in	Yes
Composite video in	2
USB ports quantity	1
Digital audio coaxial in	0
Receiver type	-
Audio output channels	7.2 channels
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	145 W
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify
Product color	Black
Audio decoders	DTS-HD Master Audio
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	430 W
Connectivity technology	Wired
Optical drive included	No
Audio formats supported	AIFF, ALAC, FLAC

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	151 mm
Weight	8500 g
