Denon AVR-X3200W Service Manual

SPK
SPK PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D9221-9224 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 4
D9230,9231 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 2
D9233,9234 nsp WIRE, COPPER(D0.6) CU97.8/SN2.1, D0.6 20050901 C3A206 2
D9241-9247 201310001503S DIODE, ULTRA-HIGH SPEED KDS160-RTK/P, KEC CVDKDS160RTKP 7
D9250 943202500720S DIODE , ZENER(3.6V/0.5W, SOD-123) CVDMM1Z3V6H 1
D9303,9304 nsp WIRE, COPPER(D0.6) CU97.8/SN2.1, D0.6 20050901 C3A206 2
D9315-9318 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 4
D9331 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9333 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9336 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9338-9340 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 3
D9343 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9345 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9347 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9349 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9701 943206500030S DIODE , BRIDGE(600V/25A) D25SB60 LRC CVDD25SB60 1
D9727 943202500840S DIODE , ZENER(7.5V/0.5W, SOD-123) CVDMM1Z7V5H 1
D9728 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 1
D9913 201310001503S DIODE, ULTRA-HIGH SPEED KDS160-RTK/P, KEC CVDKDS160RTKP 1
D9914 943202500720S DIODE , ZENER(3.6V/0.5W, SOD-123) CVDMM1Z3V6H 1
IC718 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 1
IC931 943231010390S I.C,REGULATOR(+5V,T0220IS) KIA7805BPI (KEC) CVIKIA7805BPI 1
IC933 943232100370S I.C,REGULATOR(+12V,TO220) CVIKIA7812BPI 1
IC934 943231010390S I.C,REGULATOR(+5V,T0220IS) KIA7805BPI (KEC) CVIKIA7805BPI 1
IC935 00D2631099006 I.C,REGULATOR(-5V,T0220IS) KIA7905PI (KEC) CVIKIA7905PI 1
IC936 943231101930S I.C , REGULATOR(+7V,TO-220IS) KIA7807BPI CVIKIA7807BPI 1
IC937 943231101920S I.C , REGULATOR(-7V,TO-220IS) KIA7907PI CVIKIA7907PI 1
Q9221-9224 943213500160S T.R,RT1N237C(2.2K-47K) RT1N237C(NPN,SC-59,SISAHAYA CVTRT1N237C 4
Q9230,9231 943213500160S T.R,RT1N237C(2.2K-47K) RT1N237C(NPN,SC-59,SISAHAYA CVTRT1N237C 2
RESISTOR GROUP
R7801,7802 nsp RES, M-OXIDE FILM(2W/470ohm) CRG2SANJ471RT 2
R9201-9207 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 7
R9211-9217 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 7
R9241-9247 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 7
R9250 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9251 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9711-9713 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 3
R9727 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9801-9804 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R9806 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9819,9820 nsp RES, CHIP(1608/5%/27Kohm) CRJ10DJ273T 2
R9821,9822 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 2
R9823,9824 nsp RES, CHIP(1608/5%/270ohm) CRJ10DJ271T 2
R9905,9906 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R9907,9908 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 2
R9909 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R9910 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R9911 nsp RES, CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
R9912 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9913 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R9914 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9915 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9917 943129501040S RES , CEMENT (5W, 0.01 OHM, 5% SMALL SIZE) CRF5EJR01HS 1
CAPACIITORS GROUP
C9211-9217 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 7
C9221 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1
C9250 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C9251 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C9301 nsp CAP, ELECT(16V/100uF)-S CCEA1CKS101T 1
C9303 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1
C9306 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1
C9309 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 1
C9311,9312 00MOA10801620 CAP, ELECT(16V/1000uF) CCEA1CH102E 2
C9315,9316 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 2
C9317,9318 nsp CAP, ELECT(16V/100uF)-S CCEA1CKS101T 2
C9321,9322 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 2
C9333 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C9337 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1
C9531-9537 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 7
C9631-9637 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 7
C9703 90M-OF100490R CAP, METAL PE FILM(250V/0.1uF) KCME2E104JP04T 1
C9705,9706 963134010180S CAP, ELECT(71V/12000uF),35*58L,NICHICON LKSH2123MESDZT NICHICON CCET71VLKS123N 2
C9708 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 1
C9727 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C9801-9803 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CL10C101JB8NNNC CCUS1H101JAS 3
C9804 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C9806 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CL10C101JB8NNNC CCUS1H101JAS 1
C9811 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C9905,9906 nsp CAP, ELECT(100V/1uF),85'C Black KR3-100V1R0MA CCEA2AH1R0T 2
C9909 nsp CAP, ELECT(100V/1uF),85'C Black KR3-100V1R0MA CCEA2AH1R0T 1
C9914 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C9917,9918 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 2
C9919 nsp CAP, CHIP(1608, 50V/10pF, C0G)_SAMSUNG CL10C100JB8NNNC CCUS1H100JAS 1
C9920 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CL10C101JB8NNNC CCUS1H101JAS 1
OTHER PARTS GROUP
BD981 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 1
BK901,902 nsp BRACKET, PCB(FUSE) CMD1A730 2
BK903 nsp PLATE, MAIN PCB CMC2A424 1
BN701 nsp WIRE ASS'Y LOCKING (4P,2.5MM,220MM,UL1569#20,105) CWB7E0042203D CWB7E0042203D 1
BN702 nsp WIRE ASS'Y LOCKING (5P,2.5MM,220MM,UL1569#20,105) CWB7E0052203D CWB7E0052203D 1
BN703 nsp WIRE ASS'Y LOCKING (7P,2.5MM,180MM,UL1569#20,105) CWB7E0071803D CWB7E0071803D 1
BN704 nsp WIRE ASS'Y LOCKING (6P,2.5MM,400MM,UL1569#20,105) CWB7E0064003D CWB7E0064003D 1
BN706 nsp WIRE ASS'Y (3P,2.0MM,100MM,UL1569#24,105 degree) CWB7C003100HC CWB7C003100HC 1
BN932 nsp WIRE ASS'Y LOCKING (9P,2.0MM,220MM,UL1007#26) CWB1B009220HC 1
CN25D nsp PIN HEADER (25P,1.25mm,STRAIGHT,B-TO-B) C125Z1-25 CJP25GI281Z 1
CN77D nsp PIN HEADER (19P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP19GI281Z 1
CN932 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/9PIN SMW200-09 CJP09GI288ZY 1
CN940 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/5PIN SMW250-05 CJP05GI289ZY 1
CN941 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/3PIN SMW250-03 CJP03GI289ZY 1
CN971 nsp WAFER , 7P(DIP, 3.96PITCH) YW396-07AB CJP07GA90ZY 1
! F9331 963652010510S FUSE(S506 Series, 250V,2A) S506-2A CBA2C2000TLEC 1
! F9332 963652010510S FUSE(S506 Series, 250V,2A) S506-2A CBA2C2000TLEC 1
! F9333 963652010510S FUSE(S506 Series, 250V,2A) S506-2A CBA2C2000TLEC 1
! F9334 963652010510S FUSE(S506 Series, 250V,2A) S506-2A CBA2C2000TLEC 1
! F9335 963652010510S FUSE(S506 Series, 250V,2A) S506-2A CBA2C2000TLEC 1
3

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
