Denon AVR-X3200W Service Manual

SPK
REF No. Part No. Part Name Remarks Q'ty New Ver
! F9703 943652500530D FUSE(215 Series, 250V/12A) 0215012.MXP CBA2C1202TLHEY 1
! F9704 943652500530D FUSE(215 Series, 250V/12A) 0215012.MXP CBA2C1202TLHEY 1
F9331-9335 nsp HOLDER , FUSE KJCFC5S 5
F9703,9704 nsp HOLDER , FUSE KJCFC5S 2
GND92 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 1
JK921-927 943643102420S 2P, SCREW SPK(R/B) SJ2003S-A006-00A200BJINYUE CJJ5N023Z 7
JW925A nsp WIRE ASS'Y (1P, 100mm, BLK, UL1015#20, CKM-T) CWE7102100TT CWE7102100TT 1
L9201-9207 943115010260S COIL , SPEAKER(0.5uH) SPRING COIL 8TS/KSE CLEY0R5KAK 7
RY921-924 943682010300S RELAY,G5PA-28-MC,DC12V,2C1P G5PA-28-MC, DC12V/OMOMRON CSL3A018ZE 4
RY930 943682000810S RELAY,BC3-12H,DC12V,2C2P BC3-12H/HANDOUK CSL4A016ZU 1
RY931 68201003000AS RELAY, FTR-F1CL012R, DC12V, 2C2P FTR-F1CL012R FUJITSU CSL4A021ZE 1
TU901 943183100510S TUNER , FM(SCREW : F TYPE), AM , SI4730-D60 YST990-A9U1 E3 CNVYST990-A9U1 1
TU901 943183100640S TUNER , RDS , FM(PAL TYPE) , AM , SI4731-D60 YST990-D8E2 E2 CNVYST990-D8E2 1
TU901 943183100500S TUNER , FM(PAL TYPE) , AM , SI4730-D60 YST990-A2J1 E1C CNVYST990-A2J1 1
4

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
