Denon AVR-X3200W Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
R4301 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R4303 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R4308 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R4310,4311 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R4312 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R4313-4315 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 3
R4316-4321 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 6
R4322 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R4323 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R4324 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R4326 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R4327 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R4328 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R4330-4333 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 4
R4334 nsp RES, CHIP(1005/5%/82ohm) CRJ06IJ820T 1
R4336 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 1
R4337,4338 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R4339 943113100000S COMMON MODE FILTER (1210, 90ohm) EXC24CH9000U CLZ9Z188Z 1
R4340-4342 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 3
R4351-4353 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 3
R4354,4355 nsp RES, CHIP(1005/5%/1.8Kohm) CRJ06IJ182T 2
R4356 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R4357,4358 nsp RES, CHIP(1608/1%/51ohm) CRJ10DF51R0T 2
R4367-4369 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 3
R5001-5003 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 3
R5004 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R5005 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R5006 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R5007 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R5008 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1
R5009 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R5010,5011 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 2
R5012,5013 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 2
R5016 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R5017 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R5019 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R5021 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R5023 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R5025 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R5027 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R5029 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R5031 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R5033 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R5035 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R5037 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R5039 nsp RES, CHIP(1005/5%/47ohm) CRJ06IJ470T 1
R5051-5053 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 3
R5055 nsp RES, CHIP(1005/5%/33ohm) CRJ06IJ330T 1
R5056 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R5063 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R5064-5068 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 5
R5076 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R5077 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R5082,5083 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 2
R5091 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R5093 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R5098 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1
R5115 nsp RES, CHIP(1005/5%/10ohm) CRJ06IJ100T 1
RN201 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN204 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN221 nsp RES, CHIP(1005/5%/100ohm*4) CRJ064IJ101T 1
RN251-265 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 15
RN351-354 nsp RES, CHIP(1005/5%/4.7Kohm*4) CRJ064IJ472T 4
RN391-393 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 3
RN401-415 nsp RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T 15
RN420,421 nsp RES, CHIP(1005/5%/0ohm*4) CRJ064IJ0R0T 2
RN422-428 nsp RES, CHIP(1005/5%/10ohm*4) CRJ064IJ100T 7
RN431-436 nsp RES, CHIP(1005/5%/47ohm*4) CRJ064IJ470T 6
RN437 nsp RES, CHIP(1005/5%/10ohm*4) CRJ064IJ100T 1
RN438 nsp RES, CHIP(1005/5%/33ohm*4) CRJ064IJ330T 1
RN439-441 nsp RES, CHIP(1005/5%/100ohm*4) CRJ064IJ101T 3
RN442-448 nsp RES, CHIP(1005/5%/10ohm*4) CRJ064IJ100T 7
RN449-451 nsp RES, CHIP(1005/5%/100ohm*4) CRJ064IJ101T 3
RN501 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
CAPACIITORS GROUP
C1005 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1007-1012 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 6
C1023-1026 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 4
C1031-1040 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 10
C1051 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C1053 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C1111 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1112 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1113 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1114 nsp CAP, CHIP(1608, 50V/5pF, C0G)_SAMSUNG CL10C050CB8NNNC CCUS1H050CAS 1
C1115 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1116 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1119 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1121 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1122 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1123 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1124 nsp CAP, CHIP(1608, 50V/3.3pF, C0G)_SAMSUNG CL10C3R3CB8NNNC CCUS1H3R3JAS 1
C1125 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1126 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1129 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1131 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1132 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1133 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1134 nsp CAP, CHIP(1608, 50V/3.3pF, C0G)_SAMSUNG CL10C3R3CB8NNNC CCUS1H3R3JAS 1
C1135 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1136 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1139 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1141 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1142 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1143 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1144 nsp CAP, CHIP(1608, 50V/10pF, C0G)_SAMSUNG CL10C100JB8NNNC CCUS1H100JAS 1
C1145 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1146 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1149 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1151 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1152 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1153 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1154 nsp CAP, CHIP(1608, 50V/5pF, C0G)_SAMSUNG CL10C050CB8NNNC CCUS1H050CAS 1
9

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
