Denon AVR-X3200W Service Manual

DIGITAL
REF No. Part No. Part Name Remarks Q'ty New Ver
C1155 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1156 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1159 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1161 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1162 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1163 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1164 nsp CAP, CHIP(1608, 50V/5pF, C0G)_SAMSUNG CL10C050CB8NNNC CCUS1H050CAS 1
C1165 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1166 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1169 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1171 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1172 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1173 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1174 nsp CAP, CHIP(1608, 50V/5pF, C0G)_SAMSUNG CL10C050CB8NNNC CCUS1H050CAS 1
C1175 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1176 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1179 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1181 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1182 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1183 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1184 nsp CAP, CHIP(1608, 50V/5pF, C0G)_SAMSUNG CL10C050CB8NNNC CCUS1H050CAS 1
C1185 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1186 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1189 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1191 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1192 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1193 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1194 nsp CAP, CHIP(1608, 50V/5pF, C0G)_SAMSUNG CL10C050CB8NNNC CCUS1H050CAS 1
C1195 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1196 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1199 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1201 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1202 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1203 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1204 nsp CAP, CHIP(1608, 50V/5pF, C0G)_SAMSUNG CL10C050CB8NNNC CCUS1H050CAS 1
C1205 nsp CAP, CHIP(2012, 6.3V/22uF, X5R)_SAMSUNG CL21A226KQFNNNC CCUC0J226KCS 1
C1206 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1209 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CL21B104KBFNNNC CCUC1H104KCS 1
C1211 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CL05B103KA5NNNC CCUI1E103KCS 1
C1212,1213 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 2
C1214-1218 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 5
C1219 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1220 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CL05B103KA5NNNC CCUI1E103KCS 1
C1221 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1224 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CL05B103KA5NNNC CCUI1E103KCS 1
C1225 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 1
C1226 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1231 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1232 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1233 nsp CAP,ALUMINUM ELECTROLYTIC CAPACITORS(16V/100uF) MVG SERIES CCEC1CMVG101T 1
C1235 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CL05B103KA5NNNC CCUI1E103KCS 1
C1236 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1237 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CL05B103KA5NNNC CCUI1E103KCS 1
C1238 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1241 nsp CAP,ALUMINUM ELECTROLYTIC (16V/470uF) MVG SERIES CCEC1CMVG471T 1
C1243 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1245 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1246 nsp CAP,ALUMINUM ELECTROLYTIC (16V/470uF) MVG SERIES CCEC1CMVG471T 1
C1253 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C1254,1255 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 2
C1501-1505 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 5
C1506,1507 nsp CAP, CHIP(1608, 50V/10pF, C0G)_SAMSUNG CL10C100JB8NNNC CCUS1H100JAS 2
C1508-1514 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 7
C1516-1525 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 10
C1531,1532 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 2
C1533 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1534 nsp CAP, CHIP(1005, 50V/220pF, C0G)_SAMSUNG CL05C221JB5NNNC CCUI1H221JAS 1
C1701-1705 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 5
C1902,1903 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CL05B103KA5NNNC CCUI1E103KCS 2
C1908-1913 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CL05B103KA5NNNC CCUI1E103KCS 6
C1915 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C1916 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CL05B103KA5NNNC CCUI1E103KCS 1
C2003,2004 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CL05B103KA5NNNC CCUI1E103KCS 2
C2005-2008 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 4
C2009,2010 nsp CAP, CHIP(1005, 50V/33pF, C0G)_SAMSUNG CL05C330JB5NNNC CCUI1H330JAS 2
C2014 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C2015 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C2016,2017 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 2
C2018 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C2019 nsp CAP, CHIP(1608, 50V/15pF, C0G)_SAMSUNG CL10C150JB8NNNC CCUS1H150JAS 1
C2020 nsp CAP, CHIP(1608, 50V/12pF, C0G)_SAMSUNG CL10C120JB8NNNC CCUS1H120JAS 1
C2021 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C2023 nsp CAP, CHIP(2012, 50V/4700pF, MURATA GRM21) GRM2162C1H472JA01 MURATA CCUMUC1H472JAM 1
C2024 nsp CAP, CHIP(3216, 50V/0.068uF, MURATA GRM31) GRM31C2C1H683JA01 MURATA CCUMUP1H683JAM 1
C2025 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C2026 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C2027 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C2028 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C2030,2031 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 2
C2032 nsp CAP, CHIP(1005, 25V/0.022uF, X7R)_SAMSUNG CL05B223KA5NNNC CCUI1E223KCS 1
C2205-2224 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 20
C2225 nsp CAP, CHIP(1005, 50V/100pF, C0G)_SAMSUNG CL05C101JB5NNNC CCUI1H101JAS 1
C2501-2504 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 4
C2505 nsp CAP, CHIP(1005, 50V/100pF, C0G)_SAMSUNG CL05C101JB5NNNC CCUI1H101JAS 1
C2506 nsp CAP, CHIP(2012, 6.3V/47uF, X5R)_SAMSUNG CL21A476KQANNNC CCUC0J476KCS 1
C2507 nsp CAP,ALUMINUM ELECTROLYTIC CAPACITORS(16V/100uF) MVG SERIES CCEC1CMVG101T 1
C2508 nsp CAP,ALUMINUM ELECTROLYTIC (16V/10uF) MVG SERIES CCEC1CMVG100T 1
C2509 nsp CAP, SMD ELECT(16V/47uF) 16VC47 CCEC1CMVG470T 1
C2510-2512 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 3
C2513 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C2514 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C2515,2516 nsp CAP, CHIP(1608, 50V/12pF, C0G)_SAMSUNG CL10C120JB8NNNC CCUS1H120JAS 2
C2517-2531 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 15
C2532 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 1
C2533 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C2534 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 1
C2535 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C2536 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 1
C2537 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C2538,2539 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 2
C2540 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
C2541 nsp CAP, CHIP(1005, 50V/1000pF, X7R)_SAMSUNG CL05B102KB5NNNC CCUI1H102KCS 1
C2542 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CL05B104KO5NNNC CCUI1C104KCS 1
10

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
