Denon AVR-X3200W Service Manual

SMPS
SMPS PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D9001-9006 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST 6
D9008,9009 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST 2
D9010 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 1
D9012 nsp HEATSINK ASS'Y(CVDSR3060PT+CMY3A238) CVDSR3060PTCDA CVDSR3060PTCDA 1 *
D9012-1 nsp TR HEATSINK CMY3A238 1
D9012-2 nsp SCREW CTW3+10JR 1
D9012-3 943204500520S SCHOTTKY BARRIER RECTIFIER SR3060PT TSC CVDSR3060PT 1 *
D9013 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST 1
IC901 nsp HEATSINK ASS'Y(CVITOP268EG+CMD1A942+CMY7A025+ CTB3 CVITOP268EGCHA CVITOP268EGCHA 1 *
IC901-1 nsp BRACKET , PWM IC CMD1A942 1 *
IC901-2 nsp HEATSINK , TR CMY7A025 1 *
IC901-3 nsp SCREW CTB3+8JR 1
IC901-4 943231102350S I.C , OFF-LINE POWER SWITCH TOP268EG CVITOP268EG 1 *
! IC902 963239010480S I.C , PHOTOCOUPLER PC123Y22FZ0F BRAND CVIPC123Y22FZ0F 1
IC903 212050010508S I.C,SHUNT REGULATOR(TO-92) KIA2431AP CVIKIA2431AP 1
IC904 943239100730S I.C , SYSTEM RESET(4.8V , SOT-25A) PST8448NR MITSUMI CVIPST8448NR_A 1
Q9001 943229500110S F.E.T , INK0010AC1 (N-CH, SC-59, MOSFET, ISAHAYA) INK0010AC1 ISAHAYA CVTINK0010AC1 1
Q9003 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 1
ZD9017 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD CVDZJ39BT 1
ZD908 943202500850S TVS DIODE, 120V / 5W P6KE120A LRC E3 CVDP6KE120AT 1
ZD911 943202500860S TVS DIODE, 150V / 5W P6KE150A LRC CVDP6KE150AT 1
ZD918 90M-HD302350R DIODE , ZENER ,1/2W, 27V ZJ27B/HOMI(H.K) COMPANY LTD CVDZJ27BT 1
ZD919 00D9600095607 DIODE , ZENER ,1/2W, 5.6V ZJ5.6B/HOMI(H.K) COMPANY LTD CVDZJ5.6BT 1
ZD920 00D2760762958 DIODE , ZENER ,1/2W, 39V ZJ39B/HOMI(H.K) COMPANY LTD CVDZJ39BT 1
ZD921 00D9430196306 DIODE,ZENER,1/2W,7.5V ZJ8.2B/HOMI(H.K) COMPANY LTD E3 CVDZJ7.5BT 1
ZD921 943202000940S DIODE , ZENER ,1/2W, 16V ZJ16B/HOMI(H.K) COMPANY LTD E2/E1C CVDZJ16BT 1
RESISTOR GROUP
R9004 nsp RES, CARBON(1/5W,330Kohm,J) CRD20TJ334T 1
R9006 nsp RES, CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R9008,9009 nsp RES, CARBON(1/5W,2.2Mohm,J) E3 CRD20TJ225T 2
R9010 nsp RES, CARBON(1/5W,1Mohm,J) E3 CRD20TJ105T 1
R9013 nsp RES, CHIP(3216/5%/22ohm) 3216 SIZE CRJ14CJ220T 1
R9014 nsp RES, CHIP(1608/5%/270Kohm) E3 CRJ10DJ274T 1
R9014 nsp RES, CHIP(1608/5%/56Kohm) E2/E1C CRJ10DJ563T 1
R9015 nsp RES, CHIP(1608/5%/4.7Kohm) E3 CRJ10DJ472T 1
R9015 nsp RES, CHIP(1608/5%/5.6Kohm) E2/E1C CRJ10DJ562T 1
R9016 nsp RES, CHIP(1608/5%/10Kohm) E3 CRJ10DJ103T 1
R9016 nsp RES, CHIP(1608/5%/12Kohm) E2/E1C CRJ10DJ123T 1
R9017 nsp RES, CARBON(1/5W,6.8ohm,J) CRD20TJ6R8T 1
R9018 nsp RES, CARBON(1/5W,56ohm,J) CRD20TJ560T 1
R9019 nsp RES, CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
R9020 nsp RES, CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R9021 nsp RES, CHIP(1608/1%/22Kohm) CRJ10DF2202T 1
R9024 nsp RES, CHIP(1608/1%/6.8Kohm) CRJ10DF6801T 1
R9026 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9027 nsp RES, CARBON(1/5W,4.7Kohm,J) CRD20TJ472T 1
! R9031 943121501000S RES , SURGE ,(8.2M OHM, 5%, 1/2W, PRC TYPE) PRC92T1J8M20 CRO50TJ825T 1
R9035-9037 nsp RES, CHIP(2012/5%/1Mohm) CRJ18AJ105T 3
R9038 nsp RES, CHIP(3216/5%/10ohm) CRJ14CJ100T 1
CAPACIITORS GROUP
! C9001-9003 963132011940S EOL item CAP, CERAMIC(X1/Y2,0.01uF,AC250V) DE2F3KY103MB3BM02 MURATA CCKDKY103MFM 3
C9004 943134503040S CAP, ELECT(200V/220uF),105'C NHA 200 VB 220 M E3 CCET200NHA221E
S
1
C9004 963134010200S CAP , ELECT (400V/100UF, 18X40, NHA) NHA400VB100M/SAMYOUNG E2/E1C CCET400NHA101E
S
1
C9006 nsp CAP, CHIP(1608, 50V/0.047uF, X7R)_SAMSUNG CL10B473KB8NNNC E3 CCUS1H473KCS 1
C9006-9008 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC E2/E1C CCUS1H104KCS 3
C9009 00D9430175108 CAP, ELECT(50V/10uF),105'C 5X11L/105/NXA/SAMYOUNG CCEA1HNXA100TS 1
C9010 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C9012 943132100600S CAP, CERAMIC(DC1KV/2200pF) DEHR33A222KB3B CCKDDEH222KCM 1 *
C9013,9014 943132100610S CAP, CHIP(3216, 50V/1000pF) CL31B102KBCNNNC CCUP1H102KCS 2 *
C9015 nsp CAP, CHIP(1608, 50V/0.015uF, X7R)_SAMSUNG CL10B153KB8NNNC CCUS1H153KCS 1
C9016 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C9017 00MOA47602520 CAP, ELECT(25V/47uF),105'C 5X11L/105/NXA/SAMYOUNG CCEA1ENXA470TS 1
C9018 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C9019 nsp CAP, CHIP(1608, 6.3V/4.7uF, X5R)_SAMSUNG CL10A475KQ8NNNC CCUS0J475KCS 1
C9020-9022 963134010220S CAP, ELECT(6.3V/5600uF) NXA6.3VB 5600M 5.0MC(12.5*35L) CCEA0JNXA562ES 3
C9023,9024 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 2
! C9028 963132011930S EOL item CAP, CERAMIC(X1/Y1,2200P,AC250V) DE1E3KX222MB4BL01 MURATA CCKDKX222MEM 1
C9029 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C9032 943139500110S CAP, CHIP(3216, 1KV/47pF, C0G)_SAMSUNG CL31C470JBCNNNC CCUP3A470JAS 1
OTHER PARTS GROUP
BK901,902 nsp BRACKET , PCB M3 CMD1A834 2
BK903 nsp BRACKET , PCB CMD1A629 1
BN901 nsp WIRE ASS'Y LOCKING (6P,2.5mm,350mm,UL1569#22,105) CWB7D006350AGD CWB7D006350AGD 1 *
CN901 nsp WAFER, 2P, 3.96mm CJP02KA060ZY 1
CN902 nsp WAFER, 2P, 7.92mm YW396-02AB/YEONHO CJP02GA89ZY 1
! CX901,902 943139500020S CAP , POLYPROPYLENE FILM (0.1uF/275VAC) M-CMP2D104ML12T CCQF2E104KZE-T 2
! CY901,902 963134011730S EOL item CAP, CERAMIC(X1/Y1,470P,AC250V) DE1B3KX471KB4BL01 MURATA CCKDKX471KBM 2
! F9001 963652010510S FUSE(S506 Series, 250V,2A) S506-2A E3 CBA2C2000TLEC 1
! F9001 963652010500S FUSE(S506 Series, 250V,1.6A) S506-1.6A E2/E1C CBA2C1600TLEC 1
! F9002 90M-FS001220R FUSE(218Series, 250V/8A) E3 KBA2C8000TLEY 1
! F9002 90M-FS001490R FUSE(218Series, 250V/4A) 0218004.MXP E2/E1C KBA2C4000TLEY 1
F9001,9002 nsp HOLDER , FUSE KJCFC5S 2
L9001 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 1
! LF901 943121501000S LINE FILTER(1.2A,29mH) SQE2424(12290) E3 CLZ9Z176Z 1
! LF901 943134503040S LINE FILTER(0.7A,65mH) SQE2424(07650) E2/E1C CLZ9Z177Z 1
! RY901 963682010370S RELAY,HL31-1AT-5H,DC5V,1C1P HL31-1AT-5H/HANDOUK HANDOUK CSL1C006ZE 1
! T9001 943102100690S TRANS, SWITCHING SH10344A CLT9Z119ZE 1 *
nsp SHEILD , TRANS COVER CMC1A445 1
nsp RUBBER , TRANS CHG1A587 1
nsp TAPE , BOTH SIDE C4FA101 0.02
16

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
