Denon AVR-X3200W Service Manual

VIDEO
VIDEO PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D5211 943202500740D DIODE , ZENER(16V/0.5W, SOD-123) MM1Z16 CVDMM1Z16H 1
D5251 00D2760718902 DIODE, SCHOTTKY, 30V RB521S-30, ROHM ROHM CVDRB521S-30 1
D5252 943209001080S DIODE , CHIP , SWITCHING 1SS355/HOMI(HK) COMPANY LTD CVD1SS355T 1
D5254 00D2760718902 DIODE, SCHOTTKY, 30V RB521S-30, ROHM ROHM CVDRB521S-30 1
IC511 90M-HC109700R I.C , VIDEO S/W (JRC) CVINJM2595MTE1 1
IC516 963235100630S I.C , VIDEO SW(3IN,1OUT,SSOP-20P) NJM2586AVC3 CVINJM2586AVC3 1
IC521 963239008800S I.C, RS232 (3.3V) ILX3232D CVIILX3232DT 1
Q5117 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q5211 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1
Q5212 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q5251 943215500020S T.R,RT1P141C(10K-10K) RT1P141C(PNP,SC-59,SISAHAYA CVTRT1P141C 1
Q5252 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 1
RESISTOR GROUP
R5101-5103 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 3
R5104 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 1
R5113 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5115 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5117 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5118 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 1
R5119 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5151 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5153 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5155 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5157 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5161 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5166 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5169 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5171 nsp RES, CHIP(1608/1%/75ohm) E3 CRJ10DF75R0T 1
R5173 nsp RES, CHIP(1608/1%/75ohm) E3 CRJ10DF75R0T 1
R5175 nsp RES, CHIP(1608/1%/75ohm) E3 CRJ10DF75R0T 1
R5181 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5183 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5185 nsp RES, CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5210 nsp RES, CHIP(3216/5%/0ohm) CRJ14CJ0R0T 1
R5211 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R5212 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5231-5234 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 4
R5251 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5252 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R5253 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R5254 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
CAPACIITORS GROUP
C5106 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C5107 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C5108 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C5109 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C5111-5113 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 3
C5152 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C5154 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C5156 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C5158 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C5160 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C5162 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1
C5163-5165 nsp CAP, CHIP(1608, 50V/68pF, C0G)_SAMSUNG CL10C680JB8NNNC E3 CCUS1H680JAS 3
C5166 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C5167 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C5168-5170 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 3
C5171 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C5172-5174 nsp CAP, CHIP(1608, 50V/68pF, C0G)_SAMSUNG CL10C680JB8NNNC CCUS1H680JAS 3
C5212,5213 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 2
C5214 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 1
C5231 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C5233-5235 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 3
C5236 nsp CAP, ELECT(16V/10uF)-S CCEA1CKS100T 1
C5237 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C5238,5239 nsp CAP, CHIP(1608, 50V/33pF, C0G)_SAMSUNG CL10C330JB8NNNC CCUS1H330JAS 2
C5251 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 1
C5252 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C5253 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 1
OTHER PARTS GROUP
BN21B nsp PIN SOCKET (19P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP19HJ282Z 1
BN27B nsp PIN SOCKET (19P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP19HJ282Z 1
BN28B nsp PIN SOCKET (13P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP13HJ282Z 1
JK511 943643103300S RCA JACK 3P(Y/Y/Y), SILVER PLATE RC036-F03R1BY-A CJJ4S059Z 1 *
JK513-515 943643101100S JACK, 3P(G/B/R), SILVER RCA-303D-00-08/YUQIU CJJ4S050Z 3
JK521 943646100420S JACK, 9P D-SUB FEMALE(RS-232C) D227FD009S100BY/YUQIU CJJ9W001Z 1
JK523 643010086019S JACK, STEREO (RED MOLD) PJ-308-02-RD/YUQIU CJJ2D019Z 1
JK525,526 90M-YT004860R JACK, STEREO (BLK MOLD) PJ-308-02/YUQIU CJJ2D008Z 2
JW502 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
17

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
