Denon AVR-X3200W Service Manual

FRONT CNT
FRONT CNT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
IC301 943239101080S I.C , DAC (8CH , HTSSOP-48) CVIPCM1690DCAR 1
IC302-305 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 4
IC311 943239101080S I.C , DAC (8CH , HTSSOP-48) CVIPCM1690DCAR 1
IC312 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 1
RESISTOR GROUP
R3001 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R3002 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R3003,3004 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R3011-3014 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3015-3018 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 4
R3019-3022 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 4
R3023-3026 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3027,3028 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3029-3032 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3033 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3035 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3036 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3037 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R3038 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3039 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R3040 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3041 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3042 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3043 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3045,3046 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3047 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R3049 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 1
R3053 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3055 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3057 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R3059 nsp RES, CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R3063 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3065-3068 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3069 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3071 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3073,3074 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3075-3078 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3079,3080 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3081 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3083 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 1
R3085,3086 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R3101 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R3102 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R3103,3104 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 2
R3111-3114 nsp RES, CHIP(1608/5%/15Kohm) CRJ10DJ153T 4
R3115,3116 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3117,3118 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3119-3122 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R3123,3124 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 2
R3125,3126 nsp RES, CHIP(1608/5%/150Kohm) CRJ10DJ154T 2
R3127,3128 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
CAPACIITORS GROUP
C3001 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C3002 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C3003 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C3004 00D2544577958 CAP, ELECT(16V/220uF),ELNA/RA3 RA3-16V221MF3#8P-T2 CCEA1CRA3221T 1
C3005 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C3006 nsp CAP, ELECT(10V/220uF) KR3-10V221MA(5*11L) CCEA1AH221T 1
C3007 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C3012,3013 nsp CAP, CHIP(2012, 50V/1800pF, MURATA GRM21) GRM2165C1H182JA01 MURATA CCUMUC1H182JAM 2
C3015-3018 nsp CAP, CHIP(2012, 50V/270pF, MURATA GRM21) GRM2165C1H271JA01 MURATA CCUMUC1H271JAM 4
C3021,3022 nsp CAP, ELECT(16V/470uF) 470UF 16V CCEA1CH471T 2
C3023 nsp CAP, CHIP(2012, 50V/1800pF, MURATA GRM21) GRM2165C1H182JA01 MURATA CCUMUC1H182JAM 1
C3024 nsp CAP, CHIP(2012, 50V/1000pF, MURATA GRM21) GRM2165C1H102JA01 MURATA CCUMUC1H102JAM 1
C3025 nsp CAP, CHIP(2012, 50V/270pF, MURATA GRM21) GRM2165C1H271JA01 MURATA CCUMUC1H271JAM 1
C3026 nsp CAP, CHIP(2012, 50V/150pF, MURATA GRM21) GRM2165C1H151JA01D MURATA CCUMUC1H151JAM 1
C3027 nsp CAP, CHIP(2012, 50V/270pF, MURATA GRM21) GRM2165C1H271JA01 MURATA CCUMUC1H271JAM 1
C3028 nsp CAP, CHIP(2012, 50V/150pF, MURATA GRM21) GRM2165C1H151JA01D MURATA CCUMUC1H151JAM 1
C3031 nsp CAP, CHIP(2012, 50V/1000pF, MURATA GRM21) GRM2165C1H102JA01 MURATA CCUMUC1H102JAM 1
C3032,3033 nsp CAP, CHIP(2012, 50V/150pF, MURATA GRM21) GRM2165C1H151JA01D MURATA CCUMUC1H151JAM 2
C3037,3038 nsp CAP, CHIP(2012, 50V/1800pF, MURATA GRM21) GRM2165C1H182JA01 MURATA CCUMUC1H182JAM 2
C3039-3042 nsp CAP, CHIP(2012, 50V/270pF, MURATA GRM21) GRM2165C1H271JA01 MURATA CCUMUC1H271JAM 4
C3055,3056 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 2
C3057,3058 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 2
C3061-3063 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 3
C3064-3066 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 3
C3067-3069 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 3
C3074,3075 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 2
C3101 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C3102 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 1
C3103 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C3104 nsp CAP, ELECT(10V/220uF) KR3-10V221MA(5*11L) CCEA1AH221T 1
C3105 00D2544577958 CAP, ELECT(16V/220uF),ELNA/RA3 RA3-16V221MF3#8P-T2 CCEA1CRA3221T 1
C3106,3107 nsp CAP, CHIP(1608, 10V/1uF, X7R, X7S)_SAMSUNG CL10B105KP8NNNC CCUS1A105KCS 2
C3121,3122 nsp CAP, CHIP(2012, 50V/1800pF, MURATA GRM21) GRM2165C1H182JA01 MURATA CCUMUC1H182JAM 2
C3123-3126 nsp CAP, CHIP(2012, 50V/270pF, MURATA GRM21) GRM2165C1H271JA01 MURATA CCUMUC1H271JAM 4
C3129,3130 nsp CAP, ELECT(16V/470uF) 470UF 16V CCEA1CH471T 2
C3147,3148 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 2
C3149,3150 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 2
C3153,3154 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 2
C3155,3156 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CL10B102KB8NNNC CCUS1H102KCS 2
OTHER PARTS GROUP
BN25D nsp PIN SOCKET (25P,1.25mm,ANGLE, B-TO-B) C125Z2-25 CJP25HJ282Z 1
CN21A nsp PIN HEADER (19P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP19GI281Z 1
CN21B nsp PIN HEADER (19P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP19GI281Z 1
CN24A nsp PIN HEADER (27P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP27GI281Z 1
CN24C,25 nsp PIN HEADER (23P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP23GI281Z 2
CN26A nsp PIN HEADER (09P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP09GI281Z 1
CN26C nsp PIN HEADER (15P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP15GI281Z 1
JW9602 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
JW9604 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
L3001 nsp FERRITE CHIP BEAD(2012/220R, CB05YTYH221) CB05YTYH221 CLZ9R018V 1
18

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
