Page #201 background image
SIDE CNT
SIDE CNT PCB ASS'Y
Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
OTHER PARTS GROUP
BN77D nsp PIN SOCKET (19P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP19HJ282Z 1
CN23A nsp PIN HEADER (27P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP27GI281Z 1
CN23C nsp PIN HEADER (21P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP21GI281Z 1
CN27A nsp PIN HEADER (15P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP15GI281Z 1
CN27C nsp PIN HEADER (19P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP19GI281Z 1
CN28C nsp PIN HEADER (13P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP13GI281Z 1
CN64C nsp PIN HEADER (13P,1.25mm,STRAIGHT,B-TO-B) C125Z1/COSMOS CJP13GI281Z 1
JW961 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
JW971 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
