Denon AVR-X3200W Service Manual

INPUT
REF No. Part No. Part Name Remarks Q'ty New Ver
R8740 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8741,8742 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R8743-8746 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R8747-8750 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8751,8752 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R8753 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8757,8758 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R8759 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8760 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8764 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8765,8766 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R8767 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8768 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8769 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8772,8773 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 2
R8774,8775 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R8776 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8777-8780 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8781,8782 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R8801 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8803 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8805 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1
R8807 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R8809 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R8811 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 1
R8813 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8817 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8819 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8820 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8846 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 1
R8848 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R8849 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8850,8851 nsp RES, CHIP(1608/5%/270Kohm) CRJ10DJ274T 2
R8852,8853 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 2
R8863 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8869 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8870 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R8891,8892 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 2
R8901,8902 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 2
R8911,8912 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 2
R8913-8916 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 4
R8917-8920 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 4
R8921,8922 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 2
R8923 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R8927,8928 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R8929 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R8930 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
RN101-104 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 4
CAPACIITORS GROUP
C1001-1005 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 5
C1006 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1007-1015 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 9
C1016 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C1021 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CL10B103KB8NNNC CCUS1H103KCS 1
C1022 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 1
C1023 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CL21A106KQFNNNC CCUC0J106KCS 1
C4603,4604 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C4607,4608 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C4613,4614 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C4617,4618 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C4627,4628 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C4641 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) ROB-50V470MG3#9-T2 CCEA1HROB470T 1
C4701,4702 nsp CAP, ELECT(25V/220uF) CCEA1EH221T 2
C4705 nsp CAP, ELECT(25V/220uF) CCEA1EH221T 1
C4706 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C4710,4711 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 2
C4713,4714 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 2
C4721,4722 nsp CAP, CHIP(1608, 16V/0.15uF, X7R, X7S)_SAMSUNG CL10B154KO8NNNC CCUS1C154KCS 2
C4723,4724 nsp CAP, CHIP(1608, 50V/0.047uF, X7R)_SAMSUNG CL10B473KB8NNNC CCUS1H473KCS 2
C4725,4726 nsp CAP, CHIP(1608, 50V/0.022uF, X7R)_SAMSUNG CL10B223KB8NNNC CCUS1H223KCS 2
C4727,4728 nsp CAP, ELECT(16V/470uF) 470UF 16V CCEA1CH471T 2
C4729,4730 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 2
C4742 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) ROB-50V470MG3#9-T2 CCEA1HROB470T 1
C4761-4763 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) ROB-50V470MG3#9-T2 CCEA1HROB470T 3
C4764-4768 nsp CAP, ELECT(25V/47uF) CCEA1EH470T 5
C4771 nsp CAP, ELECT(25V/47uF) CCEA1EH470T 1
C4781-4784 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 4
C4801,4802 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 2
C4803-4806 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CL10B103KB8NNNC CCUS1H103KCS 4
C4811,4812 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 2
C4819,4820 nsp CAP, CHIP(1608, 50V/68pF, C0G)_SAMSUNG CL10C680JB8NNNC CCUS1H680JAS 2
C4823,4824 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CL10C101JB8NNNC CCUS1H101JAS 2
C4825-4828 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 4
C4831,4832 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 2
C4891,4892 nsp CAP, ELECT(50V/47uF) CCEA1HH470T 2
C4901 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C4903 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C4905 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C4907 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C4909-4911 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 3
C4913 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1
C4935,4936 nsp CAP, ELECT(16V/470uF) 470UF 16V CCEA1CH471T 2
C8703,8704 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8707,8708 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8709,8710 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C8711,8712 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 2
C8713,8714 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8719 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8723,8724 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8727,8728 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8729,8730 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C8739 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8740 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CL10B103KB8NNNC CCUS1H103KCS 1
C8743,8744 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8747,8748 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8749,8750 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C8759 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8768 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8769 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8772 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8777,8778 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8779,8780 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C8781 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CL10B103KB8NNNC CCUS1H103KCS 1
21

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
