Denon AVR-X3200W Service Manual

INPUT
REF No. Part No. Part Name Remarks Q'ty New Ver
C8803 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8807 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8809 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 1
C8819 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8820 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CL10B103KB8NNNC CCUS1H103KCS 1
C8849 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C8869 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8913,8914 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8917,8918 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 2
C8919,8920 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CL10C331JB8NNNC CCUS1H331JAS 2
C8929 nsp CAP, ELECT(50V/0.47uF) CCEA1HHR47T 1
C8971 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CL10B103KB8NNNC CCUS1H103KCS 1
C8991,8992 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CL10B104KB8NNNC CCUS1H104KCS 2
OTHER PARTS GROUP
BK101 nsp BRACKET , HDMI CMD1A841 1
BN23C nsp PIN SOCKET (21P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP21HJ282Z 1
BN24C nsp PIN SOCKET (23P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP23HJ282Z 1
BN26C nsp PIN SOCKET (15P,1.25mm,ANGLE,B-TO-B) C125Z2/COSMOS CJP15HJ282Z 1
BN461 nsp WIRE ASS'Y Locking (YH) (13P,2MM,180MM,#26) CWB1B013180HC CWB1B013180HC 1
BN64C nsp PIN SOCKET (13P,1.25mm,ANGLE, B-TO-B) C125Z2/COSMOS CJP13HJ282Z 1
CN101 nsp WAFER, FFC, SMD(23P-1mm, STRAIGHT) CJP23GA193ZY 1
CN706 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/3PIN SMW200-03 CJP03GI288ZY 1
JK101 943643103000S JACK , HDMI(TYPE-A, SMT-19P, W/O FLANGE) A0D7ABAR19N0 CJJ9H022Z 1
JK461,462 943643101570S JACK, 4P(W/R,W/R),SEPA-GND RCA-405B-00-04 CJJ4P048U 2
JK463 943643010150S JACK, 2P(W/R),SEPA-GND, SILVER RCA-207AE-02/YUQIU CJJ4N034U 1
JK871 643010079004S JACK, 4P(W/R,W/B),SEPA-GND, SILVER RCA-405B-55/YUQIU CJJ4P077Z 1
JK872 943643101570S JACK, 4P(W/R,W/R),SEPA-GND RCA-405B-00-04 CJJ4P048U 1
JK875 943643010160S JACK, 1P(BK),SEPA-GND, SILVER RCA-107B-04/YUQIU CJJ4M046U 1
JK876 943643010150S JACK, 2P(W/R),SEPA-GND, SILVER RCA-207AE-02/YUQIU CJJ4N034U 1
L1001,1002 nsp FERRITE CHIP BEAD(1608/60R, CB03YTYH600) CB03YTYH600 CLZ9R005V 2
LUG11 nsp WIRE ASS'Y(1P) CWE8202080RV 1
22

Denon AVR-X3200W Specifications

General

Receiver type	Surround
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	8
Audio (L/R) in	5
Composite video in	3
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
12V trigger	Yes
Speakers connectivity type	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	vTuner
Optical drive included	No
Display	LCD
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	650 W

Weight and Dimensions

Depth	388 mm
Width	434 mm
Height	167 mm
Weight	11300 g
