Denon AVR-X3200W Service Manual

Error
Code
USB Update Error Display Details of Error code Remedies
15
U p d a t e C h e c k N G 1 5
Error in Verify after rewriting Main
(Check Sum Error).
This unit automatically retries the
request several times. Wait until the
Display stops. If the Display stops at the
Error display, press and hold the "Power
operation" button for 5 seconds.
16
U p d a t i n g f a i l 1 6
Setup failure of the XModem
transfer method.
This unit automatically retries the
request several times. Wait until the
Display stops. If the Display stops at the
Error display, press and hold the "Power
operation" button for 5 seconds.
20
C o n n e c t i o n F a i l 2 0
Unable to detect USB after SBL
Mode.
Disconnect and reconnect the USB
memory.
21
F i l e s N o t F o u n d 2 1
No Firmware File in USB after SBL
Mode.
Make sure that the Firmware File is in
the USB memory.
22
N o t M a t c h F i r m 2 2
After SBL Mode, the Firmware File
in the USB does not support your
model and area.
Make sure that the model name and
area are supported by the Firmware
File.
23
C o n n e c t i o n F a i l 2 3
Failed to obtain the entire Firm-
ware information after SBL Mode.
Start the USB Update again.
24
C o n n e c t i o n F a i l 2 4
Time Out while obtaining the
entire Firmware information after
SBL Mode.
This unit automatically retries the
request several times. Wait until the
Display stops. If the Display stops at the
Error display, press and hold the "Power
operation" button for 5 seconds.
25
C o n n e c t i o n F a i l 2 5
Failed to transit to SBL Mode.
This unit automatically retries the
request several times. Wait until the
Display stops. If the Display stops at the
Error display, press and hold the "Power
operation" button for 5 seconds.
26
D o w n l o a d f a i l 2 6
Time Out in Download (writing to
SDRAM) for Firmware Download.
This unit automatically retries the
request several times. Wait until the
Display stops. If the Display stops at the
Error display, press and hold the "Power
operation" button for 5 seconds.
27
C o n n e c t i o n f a i l 2 7
Failed to write to EEPROM after
SBL Mode.
This unit automatically retries the
request several times. Wait until the
Display stops. If the Display stops at the
Error display, press and hold the "Power
operation" button for 5 seconds.
36
C o n n e c t i o n F a i l 3 6
Unable to detect USB.
Disconnect and reconnect the USB
memory.
37
F i l e s N o t F o u n d 3 7
No Firmware File in USB.
Make sure that the Firmware File is in
the USB memory.
38
N o t M a t c h F i r m 3 8
The Firmware File in the USB does
not support your model and area.
Make sure that the model name and
area are supported by the Firmware
File.
39
C o n n e c t i o n F a i l 3 9
Time Out in USB Check.
This unit automatically retries the
request several times. Wait until the
Display stops. If the Display stops at the
Error display, press and hold the "Power
operation" button for 5 seconds.
3A
C o n n e c t i o n F a i l 3 A
Unable to detect USB for Firm-
ware Download.
Disconnect and reconnect the USB
memory.
3B
F i l e s N o t F o u n d 3 B
No Firmware File for Firmware
Download.
Make sure that the Firmware File is in
the USB memory.
72
